Bently Nevada 330930-040-01-00 3300 NSv Cavo di prolunga

SKU 330930-040-01-00

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330930-040-01-00
Origin United States
Product Type: Cavo di prolunga 3300 NSv
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.12 kg
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

330930-040-01-00 is a 4.0-meter (13.1 feet) 3300 NSv Extension Cable specified with stainless steel armor and an outer FEP jacket (Option 01), without agency approvals (Option 00).

This cable interfaces between a 3300 NSv proximity probe and a 3300 XL NSv Proximitor Sensor. The addition of the FEP-jacketed stainless steel armor provides protection against physical wear, mechanical shear, and chemical exposure in demanding industrial environments, distinguishing it from standard unarmored configurations.

Features

4.0 meters (13.1 feet) overall cable length configuration (Option 040).
Stainless steel protective armor with protective FEP jacket (Option 01).
Gold-plated brass ClickLoc miniature coaxial connectors provide a secure, twist-locking connection.
Designed to match 3300 NSv probe impedance and signal characteristics.
FEP outer jacket resists oils, chemical solvents, and high humidity.

Applications

Shaft vibration and position monitoring in narrow or restricted spaces.
Small-bore turbomachinery and aeroderivative gas turbine installations.
High-speed centrifugal compressors and pumps with limited target geometries.
Industrial machinery where mechanical armor protection against hot oils and abrasion is necessary.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330930-040-01-00	3300 NSv Extension Cable, 4.0 meters, armored with FEP jacket, no approvals
A - Cable Length Option	040	4.0 meters (13.1 feet)
B - Connector and Cable Option	01	With stainless steel armor, with FEP jacket
C - Agency Approval Option	00	Not required

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Part Number / Model	330930-040-01-00
System Compatibility	3300 XL NSv Proximity Transducer System
Cable Length	4.0 meters (13.1 feet)
Armor Type	Stainless steel armor with outer FEP (Fluorinated Ethylene Propylene) jacket
Connector Type	Gold-plated brass ClickLoc miniature coaxial connectors (male/female)
Operating and Storage Temperature	-52 degC to +177 degC (-62 degF to +351 degF)
Relative Humidity	100% condensing, non-submersible when connectors are protected (tested to IEC 68-2-3 damp heat)
Center Conductor Resistance	0.220 ohm/m (0.067 ohm/ft)
Shield Resistance	0.066 ohm/m (0.020 ohm/ft)
Cable Capacitance	69.9 pF/m (21.3 pF/ft) typical
Minimum Bend Radius	25.4 mm (1.0 in)
Typical Cable Weight	64 g/m (0.7 oz/ft)
Maximum Pull Strength	220 N (50 lb) connector-to-cable

Installation Guidelines

Proper installation of the 3300 NSv extension cable ensures stable signal transmission and mechanical durability. Follow these engineering guidelines:

Minimum Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 inch) during routing to prevent internal conductor damage.
Connector Protection: While this configuration does not include pre-installed connector protectors, it is recommended to use connector protectors or silicone self-fusing tape in wet or oil-exposed environments to prevent signal degradation. Do not use silicone tape inside the machine casing if exposed to turbine oil.
Routing: Route cables away from high-voltage lines, AC motors, and other electromagnetic interference sources. Secure cables with appropriate mounting clips without over-tightening.
Torque: Connect the probe-to-cable miniature ClickLoc connectors to finger tight, then apply a maximum recommended torque of 0.56 Nm (5 in-lb) using proper tools. Do not use pliers.
Total Length Verification: Ensure that the combined length of the proximity probe and the extension cable matches the total calibrated length of the 3300 XL NSv Proximitor Sensor (typically 5.0 m or 7.0 m).

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Cosa indica il segmento «040» nel codice 330930-040-01-00?

Il segmento «040» indica che questo cavo di prolunga ha una lunghezza complessiva di 4,0 metri (13,1 piedi).

Quale protezione del cavo offre l'opzione di connettore e cavo «01»?

L'opzione «01» specifica che il cavo è avvolto in un'armatura protettiva in acciaio inossidabile e rivestito con una guaina esterna in FEP, che lo protegge dai danni fisici e dai solventi chimici.

Posso utilizzare il cavo 330930-040-01-00 in ambienti pericolosi?

L'opzione di approvazione dell'ente «00» indica che questa specifica configurazione non riporta certificazioni per aree pericolose sull'etichetta.

Questo cavo di prolunga è compatibile con le sonde standard 3300 XL?

No, questo cavo di prolunga è progettato specificamente per il sistema di trasduttori di prossimità 3300 XL NSv e deve essere abbinato alle sonde 3300 NSv e ai sensori Proximitor 3300 XL NSv.
