The Bently Nevada 9200-02-01-10-00 is a two-wire velocity transducer engineered for continuous machinery vibration monitoring or periodic diagnostic measurements when paired with test instruments. This moving-coil device measures absolute casing vibration by generating a voltage proportional to the transducer's velocity. When selected with the integral cable configuration, the 9200-02-01-10-00 Seismoprobe provides superior resistance to corrosive environments, eliminating the need for external protective housings. It connects directly to monitoring systems to ensure dependable machinery protection and predictive maintenance data collection.
| Option Code | Description |
|---|---|
| Model: 9200 | Two-Wire Seismoprobe Velocity Transducer |
| 02 | Transducer Mounting Angle / Minimum Operating Frequency: 45 +/-2.5 degrees, 4.5 Hz (270 cpm) |
| 01 | Connector Option: Top mount |
| 10 | Mounting Base Option: Circular; M10X1 stud |
| 00 | Agency Approval Option: No approvals required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Country of Origin | United States |
| Sensitivity | 20 mV/mm/s (500 mV/in/s), +/-5% at +22 degC (+72 degF) with 25 mm/s (1 in/s) machine casing vibration at 100 Hz (6000 cpm) with a 10 kilo ohm load |
| Frequency Response | From 4.5 Hz (270 cpm) to 1 kHz (60,000 cpm); +0, -3dB typical |
| Dynamic Operating Range | 2.54 mm (0.100 in) peak-to-peak maximum displacement |
| Shock Resistance | Withstands 50 g peak maximum acceleration along nonsensitive axis |
| Transverse Sensitivity | +/-10% maximum |
| Maximum Leadwire Length | 305 meters (1,000 feet) maximum between transducer and 3300 or 3500 Monitor |
| Operating & Storage Temperature | -29 degC to +121 degC (-20 degF to +250 degF) |
| Relative Humidity | Up to 95% noncondensing; 100% non-submerged when ordered with integral cable |
| Case & Adapter Material | Anodized aluminum A204 |
| Gasket Material | Neoprene |
| Connector Material (Top/Side) | Cadmium-plated aluminum, neoprene, and silver-plated copper |
| Mounting Torque (M10x1 base) | 5.6 Nm (50 inlb) |
| Height | 102 mm (4 in) typical (depends on connector option) |
| Diameter | 41 mm (1.6 in) typical |
| Weight | 300 grams (10.5 ounces) typical |
| Connector Pin | Function |
|---|---|
| Pin A | Positive output signal (goes positive with respect to Pin B when case velocity moves toward connector) |
| Pin B | Negative output signal / Return |
| Category | Standard / Certification |
|---|---|
| EMC | EN61326-1, Electrical Equipment for Measurement, Control, and Laboratory use |
| European Directives | EMC Directive 2004/108/EC |
