The CX9020-N031-0002 (CX9020N0310002) is a compact, DIN rail-mountable Ethernet control system engineered for high-performance automation tasks. Driven by a powerful 1 GHz ARM Cortex-A8 processor, this Basic CPU module serves as the intelligence hub for decentralized control architectures. This specific configuration features a factory-integrated RS485 interface, providing seamless connectivity for legacy serial devices and point-to-point communication. In demanding industrial environments such as water treatment facilities, smart building automation, and distributed power generation, the CX9020-N031-0002 ensures maximum system uptime by consolidating PLC, Motion Control, and Visualization into a single, robust hardware platform.
The N031 suffix designates a specialized hardware expansion: the RS485 interface via a 9-pin D-sub socket. Engineered for reliability, this module is configured as a "drop point" without echo, making it ideal for bus-system integration where multiple slaves communicate with a master controller. The termination is set to "off" by default, allowing engineers to implement external termination based on specific network topology requirements. Unlike standard PC interfaces, this module is directly integrated into the CX9020 system image, ensuring low-latency data polling and high-speed processing of Modbus RTU or other serial protocols.
| Attribute | Specification Details |
| Model | CX9020-N031-0002 |
| Brand | BECKHOFF |
| Processor | ARM Cortex-A8, 1 GHz |
| Interface Type | RS485 (9-pin D-sub socket) |
| Configuration | Drop point, without echo, termination off |
| Operating System | Windows Embedded Compact 7 |
| Memory | 1 GB DDR3 RAM (Internal) |
| Operating Temp | -25 to +60 deg C |
| Shipping Weight | 2.0 kg |
| Dimensions | 99 mm x 122 mm x 91 mm |
| Power Consumption | Max 12 W |
How is the RS485 termination managed on the CX9020-N031-0002?
The internal termination for this module is set to "off". For reliable data transmission over long distances or high baud rates, an external 120 Ohm resistor must be applied at the physical start and end points of the RS485 bus to prevent signal reflection.
Can this unit be used as a replacement for older CX9010 units?
Yes, the CX9020 series is the direct successor to the CX9010. It offers significantly higher processing power and memory. However, the TwinCAT project must be recompiled for the ARM architecture and the hardware configuration updated in the System Manager to recognize the N031 RS485 interface.
What is the environmental resilience rating for this CPU module?
The module is designed for extended thermal ranges, supporting operations from -25 to +60 deg C. The fanless design reduces mechanical failure points, making it highly suitable for high-vibration applications in the renewable energy sector.
Shielding and Grounding: To mitigate Electromagnetic Interference (EMI) on the RS485 line, use high-quality twisted-pair shielded cable. The shield should be grounded at a single point (typically the control cabinet entry) to avoid ground loops that could corrupt the CPU's internal logic.
Thermal Management: Although the CX9020-N031-0002 is fanless, maintain a minimum of 30 mm clearance above and below the unit for natural convection. Vertical mounting on a horizontal DIN rail is the preferred orientation to optimize heat dissipation.
MicroSD Handling: Ensure the MicroSD card (containing the OS and TwinCAT runtime) is properly seated and locked before powering the unit. Never remove the storage media while the "Disk" LED is active to prevent file system corruption.
The BECKHOFF CX9020 series utilizes a magnesium alloy and high-grade polycarbonate housing that provides superior structural integrity compared to standard plastic controllers. Its solid-state design, free of rotating parts, ensures long-term stability in mining and heavy manufacturing where 24/7 operation is critical. The N031 RS485 module is galvanically isolated, protecting the core CPU from high-voltage transients often encountered in industrial serial networks.
