The ASD-A2-1543-E (ASD-A2-1543-E) is a high-performance 1.5 kW AC servo drive from Delta’s premium ASDA-A2 series. Designed for high-precision motion control, this drive is built to handle complex tasks such as multi-axis synchronization, electronic cam (E-CAM) profiles, and high-speed point-to-point positioning. Its advanced control algorithms make it an ideal selection for industrial applications in CNC machining, semiconductor wafer handling, robotics, and advanced packaging automation where reliability and extreme positioning accuracy are required.
This model is configured for 400 V three-phase power input, ensuring compatibility with heavy-duty industrial power grids. The "E" model designation indicates support for advanced communication and control features within the A2 framework. The drive is designed to manage the high dynamic demands of 1.5 kW motor systems, providing smooth torque delivery and rapid response times. Its robust internal cooling and high-efficiency power stage ensure consistent operation under continuous load, making it a dependable choice for high-throughput production lines.
| Feature | Specification |
| Model | ASD-A2-1543-E |
| Brand | DELTA |
| Rated Output Power | 1.5 kW |
| Input Voltage | 400 V |
| Input Phase | 3-phase |
| Series | ASDA-A2 |
| Weight | 2.89 kg |
| Shipping Weight | 4 kg |
What are the primary benefits of the ASDA-A2 series?
The A2 series is Delta's high-end motion controller line. Compared to standard servo drives, it offers advanced features like built-in E-CAM, high-resolution feedback support, and superior vibration suppression, allowing for much smoother motion in complex mechanical linkages.
Is this drive suitable for my 400 V industrial facility?
Yes. The "43" designation confirms it is rated for 400 V three-phase power. Ensure your power supply is stable within the drive's specified voltage tolerance to prevent undervoltage or overvoltage trips during peak load.
What control modes are supported?
The ASDA-A2-E supports versatile control modes, including position, speed, and torque control, as well as internal position control (Pr mode), which allows the drive to store and execute sequences of motion profiles independently.
Thermal Management: The 1.5 kW drive should be mounted vertically in a clean, ventilated control panel. Maintain at least 50 mm of space above and below the unit to allow for efficient heat dissipation.
Safety Interlocks: Integrate the drive’s STO (Safe Torque Off) function into the machine’s main safety loop. Do not bypass safety features, as they are essential for personnel protection during machine maintenance.
Shielding: To maintain the precision of the motion commands, all motor power leads and encoder cables must be shielded. Terminate shields at the drive's designated ground lug to minimize the impact of high-frequency switching noise on the control network.
Global Express Shipping
Returns & Warranty
Manufacturer: Delta Electronics
Product No.: ASD-A2-1543-E
Country of origin:United States
Product Type: ASDA-A2 Series Servo Drives
Payment: T/T, Western Union
Weight: 2890g
Shipping port: Xiamen
Warranty: 12 months
