Engineered for high-precision motion control applications, the ASD-A3-2023-L is a high-performance AC servo drive within the ASDA-A3 series. This driver provides exceptional command-tracking performance and superior control accuracy, utilizing an advanced Space Vector Pulse Width Modulation (SVPWM) control algorithm for the main circuit. Designed to drive premium brushless AC servo motors, it delivers robust continuous power and incorporates dynamic features suitable for sophisticated industrial automation systems.
The unit features a feedback resolution of 24-bit, translating to 16,777,216 pulses per revolution for micro-positioning accuracy. Configured with an integrated fan cooling system and a built-in regenerative resistor, the ASD-A3-2023-L effectively manages thermal dissipation and energy feedback during rapid deceleration phases, ensuring sustained operational reliability under demanding cycle rates.
| Manufacturer | Delta Electronics |
| Part Number / Model | ASD-A3-2023-L |
| Series | ASDA-A3 |
| Product Type | AC Servo Drive |
| Phase / Input Voltage | Three-phase 220 VAC |
| Permissible Voltage Range | Three-phase 200 to 230 VAC (-15% to 10%) |
| Input Current (Three-Phase) | 13.36 A |
| Continuous Output Current | 131.4 A |
| Instantaneous Max Output Current | 53.03 A |
| Main Circuit Control | SVPWM Control |
| Drive Resolution | 24-bit (16,777,216 p/rev) |
| Speed Control Range | 1 : 6000 |
| Smoothing Strategy | Low-pass and P-curve filter |
| Tuning Modes | Auto / Manual |
| Regenerative Resistor | Built-in |
| Cooling System | Fan Cooling |
| Dimensions (L x W x H) | 18 cm x 20 cm x 9.5 cm |
| Weight | 2.7 kg |
To ensure optimal performance and avoid thermal build-up, the AC servo drive must be mounted vertically on a flat, non-flammable surface. Ensure a minimum clearance of 50 mm above and below the drive housing to allow unrestricted airflow from the built-in cooling fan. Shielded twisted-pair cabling is recommended for all control signal lines to prevent electromagnetic interference. Properly connect the ground terminal to the main system ground point to ensure safe and stable operation.
