EL1872-0010 | BECKHOFF | EtherCAT Terminal 16-Channel Digital Input Module

SKU EL1872-0010

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: EL1872-0010
  • Origin Germany
  • Product Type: EtherCAT Terminal
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Dimensions: 12 mm x 100 mm x 73 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EtherCAT Digital Input Terminals
Quantità
Call sales Contact

Product Description

Description

The EL1872-0010 is a high-density 16-channel digital input terminal from Beckhoff, optimized for industrial automation systems requiring compact signal acquisition. This terminal utilizes ground switching technology and is designed specifically for flat-ribbon cable connectivity, streamlining the wiring process for high-channel-count applications. With a rapid 10 µs input filter, it provides fast and precise monitoring of 24 V DC signals, making it suitable for high-speed sensor interfacing within an EtherCAT network.

Features

  • 16 digital input channels in a compact housing
  • Ground switching (0 V) logic interface
  • Fast 10 µs input filter for high-speed response
  • Efficient flat-ribbon cable connectivity (AWG 28)
  • Integrated signal LEDs for per-channel status monitoring
  • Electrical isolation of 500 V between E-bus and field potential

Technical Specifications

Feature Specification
Manufacturer Beckhoff
Model EL1872-0010
Number of Inputs 16
Logic Type Ground switching
Signal Voltage ("0") 18 to 30 V DC
Signal Voltage ("1") 0 to 7 V DC
Input Filter Typ. 10 µs
Current Consumption (E-bus) Typ. 100 mA
Dimensions (W x H x D) 12 mm x 100 mm x 73 mm
Operating Temperature 0 to +55 degC
Storage Temperature -25 to +85 degC

Installation Guidelines

  • Connection: The terminal is designed for use with standard flat-ribbon cables (1.27 mm spacing, AWG 28). Ensure correct orientation of the ribbon cable connector to prevent signal misalignment.
  • Mounting: Secure to a standard 35 mm DIN rail (EN 60715) using the integrated lock. The terminal supports side-by-side mounting via a double slot and key connection.
  • Power Supply: The module consumes approximately 45 mA from the 24 V supply for internal operations (excluding field load). Ensure your power supply capacity accounts for the cumulative load of all 16 channels.
  • Environmental: The unit is IP20 rated. Maintain operation within the specified 0 to +55 degC range to ensure long-term reliability.

Compliance and Certifications

  • CE, UL
  • EMC immunity/emission: Conforms to EN 61000-6-2 / EN 61000-6-4
  • Vibration/shock: Conforms to EN 60068-2-6 / EN 60068-2-27
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary benefit of using the EL1872-0010?
The primary benefit is high-density signal acquisition (16 channels) in a compact form factor using flat-ribbon cables, which simplifies wiring in automation cabinets.
Does this terminal use source switching or ground switching?
The EL1872-0010 utilizes ground switching logic.
What is the response time of the input filter?
The input filter provides a response time of approximately 10 µs.
What kind of cable is required for connecting to this terminal?
It requires standard flat-ribbon cables (1.27 mm spacing, AWG 28) for the connection.
