HIMA HIQuad X F 3221 16 Fold Input Module

SKU F3221

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: HIMA
  • Product No.: F3221
  • Origin Germany
  • Product Type: Digital Input Modules
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.12 kg
  • Dimensions: 2.1cm x 19.1cm x 12.9cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Input Modules HIQuad X

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

HIMA HIQuad X F 3221 16 Fold Input Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The F 3221 (also designated as F3221) is a safety-related 16-fold digital input hardware component engineered for deployment within HIMA HIQuad X high-integrity programmable electronic safety systems. This specific assembly functions to receive, monitor, and process binary signal data or voltage transitions tracking from field-located binary sensors or 24 V mechanical switching contacts. Operating with structural non-interacting (R non-interacting) logic segregation, the module safeguards internal system backplane communication from high-voltage transients while establishing absolute safety isolation barrier boundaries. This component serves critical processing loops to relay field instrumentation device states back into central controller frameworks safely under strict safety isolation limits.

Features

  • Processes 16 discrete input channels with a non-interacting circuit topology
  • Provides specialized safety isolation for integrated sensors or binary inputs
  • Fast technical processing cycle with a typical switching time of 10 ms
  • Compact backplane architecture requiring exactly 4 TE of rack sub-assembly space

Applications

  • High-reliability safety isolation for field binary sensors within HIQuad X architectures
  • Digital input marshalling within emergency shutdown systems
  • Safety-instrumented industrial automation processing loops

Ordering Information

Part Type Designation Alternative Designation Functional Description
F 3221 F3221 16-fold input module, safety related



Technical Specifications

Parameter Value
Manufacturer HIMA Paul Hildebrandt GmbH + Co KG
Model F 3221 / F3221
System Compatibility HIQuad X
Inputs 1-signal, 8 mA (incl. cable plug) or mechanical contact 24 V
Switching Time typ. 10 ms
Space Requirement 4 TE
Operating Data (5 V DC) 5 V DC: 70 mA
Operating Data (24 V DC) 24 V DC: 130 mA



Connections/Interfaces

System Component Link Interface Type Designation
Front Connector Interfacing Z 7116 / 3221
System Bus Interfacing I/O bus
