Honeywell 51109516-200 Experion PKS TDC 3000 Internal Power and Interface Cable Assembly

SKU 51109516-200

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: 51109516-200
  • Origin United States
  • Product Type: DCS Cable Assemblies
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Dimensions: 350 mm x 45 mm x 30 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

DCS Cable Assemblies Experion PKS TDC 3000
Quantità
Call sales Contact

Product Description

Description

The Honeywell 51109516-200 is an internal power and interface cable assembly designed for Honeywell Distributed Control Systems (DCS), including Experion PKS (C200/C300) and TDC 3000 architectures. It serves as a power and interconnect harness for fan trays, cabinet sub-racks, and system modules within control enclosures.

Built to Rev. H specifications, the 51109516-200 cable assembly connects internal cooling fan modules and routes sub-rack power distribution lines. Designed with high noise immunity to withstand industrial environments with electromagnetic interference (EMI), it supports long-term continuous duty in chemical processing, oil & gas, and power generation applications.

Features

  • Connects internal cooling fan modules and sub-rack power distribution lines within DCS enclosures
  • Engineered with high noise immunity to withstand industrial environments with electromagnetic interference (EMI)
  • Pre-terminated keyed multi-pin quick-connect terminals allow rapid hot-swap or field replacement during cabinet maintenance
  • Revision H build standard ensures updated wiring specs and insulation standards

Applications

  • Subsystem powering and fan tray interconnections within DCS enclosures
  • Sub-rack power distribution and internal interconnectivity in Experion PKS (C200/C300) systems
  • Cabinet power and interface harness integration in TDC 3000 DCS architecture
  • Industrial control cabinet wiring in chemical processing, oil & gas, and power generation environments

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Part Number 51109516-200
Revision Level Rev. H
Assembly Type Internal Power & Interface Cable Assembly
System Compatibility Honeywell Experion PKS (C200/C300), TDC 3000 DCS
Conductor Material High-grade stranded copper
Jacket / Insulation Heavy-duty industrial PVC / Polyurethane
Connector Configuration Keyed multi-pin quick-connect terminals
Condition Tested (1x Unit available)

Installation Guidelines

  • Ensure correct orientation of keyed multi-pin quick-connect terminals prior to mating with sub-rack or fan tray receptacles.
  • Route and secure cable assemblies within enclosures to prevent mechanical stress on pre-terminated connectors.
  • Maintain proper cabinet grounding and shield isolation practices to preserve signal integrity and EMI immunity.
  • Observe facility maintenance procedures when performing field replacement or hot-swap operations.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the Honeywell 51109516-200 used for?
The Honeywell 51109516-200 is an internal power and interface cable assembly used to connect fan trays, cabinet sub-racks, and system modules in Honeywell DCS enclosures.
Which system architectures support the cable assembly?
The cable assembly is compatible with Honeywell Experion PKS (C200/C300) and TDC 3000 DCS architectures.
What connector configuration does the cable assembly feature?
The assembly features pre-terminated, keyed multi-pin quick-connect terminals designed for rapid field replacement and hot-swap maintenance.
What materials are used for the conductors and insulation?
The cable assembly uses high-grade stranded copper conductors and a heavy-duty industrial PVC / Polyurethane jacket and insulation.
What build standard revision applies to part number 51109516-200?
The 51109516-200 cable assembly is built to Revision H (Rev. H) wiring and insulation standards.
