Honeywell 51309204-175 MC-TLPA02 TDC 3000 Power Adapter Board

SKU MC-TLPA02

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: MC-TLPA02
  • Origin United States
  • Product Type: DCS Power Modules
  • Payment: T/T, Western Union
  • Weight: 1.5 kg
  • Dimensions: 24.5 cm x 18.0 cm x 6.5 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

DCS Power Modules TDC 3000

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell 51309204-175 MC-TLPA02 TDC 3000 Power Adapter Board

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Honeywell MC-TLPA02 is a conformally coated Power Adapter board designed for the High-Performance Process Manager (HPM) subsystem within the TDC 3000 / TotalPlant Solution (TPS) architecture. It provides essential communication routing and power interfacing between an Input/Output Processor (IOP), such as the MU-PLAM02 or MC-PLAM02 Low Level Multiplexer (LLMux) IOP, and corresponding Field Termination Assemblies (FTAs). The board plays a critical role in integrating temperature measurement devices and serial interfaces into the core control system, enabling seamless data flow across the Universal Control Network (UCN).

Features

  • Conformal Coating: Specifically treated to protect electronic circuitry against moisture, corrosion, and harsh environmental contaminants.
  • System Interoperability: Establishes a communication bridge between the LLMux IOP and up to two Thermocouple (TC) or Resistive Temperature Device (RTD) FTAs.
  • Flexible Application: Supports both non-CE Compliant and CE Compliant configurations when deployed with appropriate Honeywell cabling and card files.
  • Extended Cable Support: Accommodates internal cabinet and external cabinet cabling configurations to support remote hardware distribution.

Applications

  • Low Level Analog Input Multiplexer (LLMux) configurations for RTD and Thermocouple sensors.
  • Serial Device Interface (SDI) and Serial Interface (SI) power adapter placements.
  • Petrochemical, refining, and continuous heavy industrial processing plants utilizing Honeywell TDC 3000 / TPS automation frameworks.

Technical Specifications

Parameter Value
Manufacturer Honeywell
Model MC-TLPA02
Part Number 51309204-175
Product Type Power Adapter
Coating Conformal Coating
Input Voltage Range 85-265 VAC
Output Voltage 24 VDC
Output Current 25 amps
System Compatibility TDC 3000 / TPS High-Performance Process Manager (HPM)
Associated IOP Models MU-PLAM02 / MC-PLAM02
Associated FTA Models MU-TAMR03, MC-TAMR03, MU-TAMT03, MC-TAMT03, MU-TAMT13, MC-TAMT13

Installation Guidelines

  • CE Compliance: For CE Compliant installations, the power adapter must be interconnected using the model MU-KFTSxx IOP to FTA cable and the corresponding IOP must be seated in a CE Compliant card file.
  • Cabinet Placement: The board is designed for physical placement alongside relevant card files or within standard vertical/horizontal mounting channels depending on configuration constraints.
  • Shield Grounding: Ensure all external cabinet cabling shields are terminated appropriately at both the Power Adapter end and the FTA end to avoid signal degradation or interference.
  • Power Cabling: All incoming AC power cabling and high-current wires should follow standard separation guidelines from low-level signal pairs within the cabinet routing channels.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the power supply board?
The device acts as a Power Adapter that enables communication and power routing between a Low Level Multiplexer (LLMux) Input/Output Processor (IOP) and its related Field Termination Assemblies (FTAs).
Does the module feature conformal coating?
Yes, this specific part number represents the conformally coated version of the Power Adapter, which provides extra environmental protection against harsh atmosphere contaminants.
What are the input and output electrical ratings for the device?
The power supply features an input voltage range of 85-265 VAC, providing a regulated output voltage of 24 VDC at a maximum output current of 25 amps.
Which Field Termination Assemblies are compatible with the power supply?
It is compatible with Low Level Analog Input Multiplexer assemblies, including Thermocouple FTAs (models MU-TAMT03/13) and Resistive Temperature Device FTAs (model MU-TAMR03).
