Engineered for continuous-duty industrial burner applications, the Honeywell C7076F1006 is a high-sensitivity, self-checking ultraviolet flame detector. This industrial sensor detects UV radiation emitted by combustion flames and is specifically configured with an integrated dynamic self-checking shutter mechanism to test detector functionality continuously. Encased in a robust, explosion-proof enclosure, this device is designed for deployment in hazardous environments where explosive gas mixtures may be present, ensuring high reliability in critical safety systems.
The unit's optical sensor responds only to ultraviolet wavelengths, ignoring infrared radiation and hot refractory surfaces. This makes it highly effective for monitoring gas, oil, or combined-fuel burners. Its durable housing features a 1-inch NPT mechanical connection for secure installation directly onto the burner viewport.
| Manufacturer | Honeywell |
| Part Number / Model | C7076F1006 |
| Sensor Type | Ultraviolet (UV) |
| Supply Voltage | 220 to 240 Vac (50/60 Hz) |
| Shutter Coil Voltage | 120 Vac |
| Hazardous Area Classification | ATEX II 2 G Ex d IIC T6 (Zone 1 and Zone 2) |
| Mechanical Connection | 1 inch NPT |
| Protection Class | IP66 |
| Ambient Temperature Range | -40 to 70 degC |
| Weight | 3.0 kg |
Position the detector so it has an unobstructed line of sight to the first third of the flame, which is the zone of highest UV intensity. Ensure the 1-inch NPT connection is sealed against pressure leaks to prevent hot gases from damaging the optical quartz window. Ground the detector housing in accordance with local industrial electrical codes to minimize electromagnetic interference. Cable runs should be kept away from high-voltage igniter wiring.
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: C7076F1006
Country of origin:United States
Product Type: Flame Detectors
Payment: T/T, Western Union
Weight: 3000g
Shipping port: Xiamen
Warranty: 12 months
Engineered for continuous-duty industrial burner applications, the Honeywell C7076F1006 is a high-sensitivity, self-checking ultraviolet flame detector. This industrial sensor detects UV radiation emitted by combustion flames and is specifically configured with an integrated dynamic self-checking shutter mechanism to test detector functionality continuously. Encased in a robust, explosion-proof enclosure, this device is designed for deployment in hazardous environments where explosive gas mixtures may be present, ensuring high reliability in critical safety systems.
The unit's optical sensor responds only to ultraviolet wavelengths, ignoring infrared radiation and hot refractory surfaces. This makes it highly effective for monitoring gas, oil, or combined-fuel burners. Its durable housing features a 1-inch NPT mechanical connection for secure installation directly onto the burner viewport.
| Manufacturer | Honeywell |
| Part Number / Model | C7076F1006 |
| Sensor Type | Ultraviolet (UV) |
| Supply Voltage | 220 to 240 Vac (50/60 Hz) |
| Shutter Coil Voltage | 120 Vac |
| Hazardous Area Classification | ATEX II 2 G Ex d IIC T6 (Zone 1 and Zone 2) |
| Mechanical Connection | 1 inch NPT |
| Protection Class | IP66 |
| Ambient Temperature Range | -40 to 70 degC |
| Weight | 3.0 kg |
Position the detector so it has an unobstructed line of sight to the first third of the flame, which is the zone of highest UV intensity. Ensure the 1-inch NPT connection is sealed against pressure leaks to prevent hot gases from damaging the optical quartz window. Ground the detector housing in accordance with local industrial electrical codes to minimize electromagnetic interference. Cable runs should be kept away from high-voltage igniter wiring.
