Honeywell CC-PFB801 Experion PKS C300 Fieldbus Interface Module

SKU CC-PFB801

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: CC-PFB801
  • Origin United States
  • Product Type: Fieldbus Interface Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.4 kg
  • Dimensions: 12.5 cm x 14.0 cm x 4.5 cm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Experion PKS Fieldbus Interface Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell CC-PFB801 Experion PKS C300 Fieldbus Interface Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Honeywell CC-PFB801 is a fieldbus interface module designed for industrial process control and field device integration within the Experion PKS C300 controller platform. The CC-PFB801 provides continuous communication, data access, control execution, diagnostics, and alarm routing between FOUNDATION Fieldbus H1 field devices and the Experion system. Equipped with high-capacity processing hardware, the module interfaces directly with standard FOUNDATION Fieldbus H1 links via dedicated physical connections to achieve real-time process monitoring and control.

Features

  • Integrates FOUNDATION Fieldbus H1 field devices with the Experion PKS C300 Controller and ACE node
  • Configurable for redundant or non-redundant operation
  • High-capacity architecture supporting integrated data access, control execution, diagnostics, and alarm management
  • Automatic recognition and detection of uncommissioned field devices connected to the link
  • Unified control strategy execution allowing process function blocks and fieldbus blocks to mix within Control Builder

Applications

  • Distributed control system (DCS) process automation
  • Field instrument integration and digital fieldbus communication networks
  • Process plant asset management and continuous condition monitoring

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model CC-PFB801
Product Type Fieldbus Interface Module (FIM8)
Fieldbus Protocol FOUNDATION Fieldbus H1
Supported H1 Links 8 links
Redundancy Support Redundant or non-redundant configuration
System Integration Experion PKS C300 Controller, ACE node
Engineering Software Control Builder

Installation Guidelines

  • Ensure proper chassis or mounting base alignment prior to inserting the module into the C300 controller assembly.
  • Verify proper shielding and grounding on all fieldbus cable connections to mitigate electromagnetic interference (EMI/RFI).
  • Maintain proper fieldbus segment termination resistor placements at both ends of each H1 fieldbus link segment.
  • Follow standard electro-static discharge (ESD) precautions during handling and installation.
