Honeywell MC-TDIY22 Experion PMIO Digital Input Field Termination Assembly

SKU MC-TDIY22(1-10 day)

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: MC-TDIY22(1-10 day)
  • Origin United States
  • Product Type: Field Termination Assemblies
  • Payment: T/T, Western Union
  • Weight: 3.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Field Termination Assemblies PMIO
Quantità
Call sales Contact

Product Description

Description

Designed for seamless integration within industrial process control systems, the Honeywell MC-TDIY22 functions as a high-density, 32-channel Digital Input Field Termination Assembly (FTA). This module serves as the critical physical interface between field-level discrete sensors and the Honeywell Process Manager I/O (PMIO) subsystem, enabling reliable system control and real-time data acquisition.

Engineered to handle 24 VDC digital input signals, the MC-TDIY22 conditions, isolates, and routes electrical signals from field equipment to control processors. Its robust construction ensures stable operation under demanding thermal and electrical conditions, making it suitable for continuous-duty industrial applications.

Features

  • Supports up to 32 discrete digital input channels for high-density signal integration.
  • Compatible with 24 VDC nominal field input signals.
  • Facilitates direct, secure termination of field wiring to Honeywell Process Manager systems.
  • Robust physical design optimized for cabinet installation and industrial environment resilience.

Applications

  • Petrochemical and chemical processing facilities.
  • Oil and gas refining and distribution networks.
  • Power generation and utility control systems.
  • Heavy industrial automated process control plants.

Technical Specifications

ManufacturerPart Number/ModelProduct TypeSystem CompatibilityNumber of ChannelsNominal Operating VoltageShipping Weight
Honeywell
MC-TDIY22
Digital Input Field Termination Assembly (FTA)
Experion PKS / TDC 3000 PMIO Systems
32 Inputs
24 VDC
3 kg

Installation Guidelines

To ensure safe and reliable operation of the MC-TDIY22, please adhere to the following installation protocols:

  • Power Isolation: Always isolate and turn off all power sources supplying the cabinet and field devices before installing or wiring the FTA.
  • Mounting: Mount the assembly securely on the standard designated FTA mounting channels within an approved, dust-free industrial control enclosure.
  • Wiring practices: Maintain clear segregation between low-voltage DC input signal wiring and high-voltage AC power distribution cabling to prevent electromagnetic noise coupling.
  • Grounding: Connect the assembly to the system ground bus in strict accordance with Honeywell engineering standards and local electrical codes.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Honeywell MC-TDIY22?
The Honeywell MC-TDIY22 is a Digital Input Field Termination Assembly (FTA) that interfaces 32 discrete digital input signals from field devices with Honeywell PMIO controller modules, operating at 24 VDC.
What systems are compatible with the MC-TDIY22 module?
The MC-TDIY22 is designed for compatibility with Honeywell Experion PKS and TDC 3000 Process Manager I/O (PMIO) systems.
How many input channels does this Field Termination Assembly support?
The assembly supports up to 32 independent digital input channels.
