The Honeywell XC5010C is a computer module designed for building management control and monitoring systems. The unit utilizes a Toshiba TMP93CS41F 16-bit microprocessor and operates within the Excel 500/600 control system architecture. It provides freely programmable direct digital control (DDC) functions and energy management features for medium-sized facilities such as offices, schools, and hospitals. The device features an open LONWORKS bus interface using an FTT-10A Free Topology Transceiver with a Neuron chip 3120, along with a C-bus communication port, an RS 232 port for MMI, modem, or terminal adapters, and a gold capacitor data buffer supporting a 72-hour memory backup.
| Order code | Description |
|---|---|
| XC5010C | Computer module Excel 500 (required for Distributed I/O) |
| Technical Parameter | Specification Value |
|---|---|
| Manufacturer | Honeywell |
| Microprocessor | Toshiba TMP93CS41F 16-bit |
| Total Memory | 1.28 MB (2x512 KB Flash EPROM, 2x128 KB RAM) |
| Memory Buffer | Gold capacitor buffer for 72 hours |
| Communication Ports | RS 232 (MMI/modem/ISDN), RS 485 (C-bus), LONWORKS (FTT-10A) |
| Housing Dimensions (H x W x D) | 5-5/8 x 7-1/2 x 7-3/8 in. (144 x 192 x 188 mm) |
| Ambient Temperature (Operation) | 32 to 122 degF (0 to 50 degC) |
| Ambient Temperature (Storage) | -4 to 158 degF (-20 to 70 degC) |
| Ambient Humidity | 5 to 93% r.h. noncondensing |
| Protection Class | IP 30 |
| Connector Pin | Function |
|---|---|
| Pin 8 | Coding pin |
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: XC5010C
Country of origin:United States
Product Type: CPU Computer Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 400g
Dimensions: 144 x 192 x 188 mm
Shipping port: Xiamen
Warranty: 12 months
