ICS Triplex

ICS Triplex T8111 Trusted TMR Processor Module

SKU T8111

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ICS Triplex
  • Product No.: T8111
  • Origin Mexico
  • Product Type: Processor Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 1.89 kg
  • Dimensions: 93 mm x 266 mm x 303 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ICS Triplex T8111 Trusted TMR Processor Module

Quantità

Product Description

Description

ICS Triplex T8111 is a fault-tolerant main processing component designed for the Trusted system architecture. Operating in a Triple Modular Redundant (TMR) lock-step configuration across three independent Processor fault containment regions (FCRs), the T8111 executes user-defined application programs, performs system monitoring, and manages I/O data exchanges across the triplicated Inter-Module Bus. The module integrates two configurable RS422/485 serial ports, one dedicated RS485 2-wire serial port, an RS232 front panel diagnostic interface, and built-in IRIG-B time synchronization capabilities. The ICS Triplex T8111 is designed for critical safety instrumented functions and process control applications requiring high availability and fault isolation.

Features

  • Triple Modular Redundant (TMR) architecture with Hardware Implemented Fault Tolerant (HIFT) clock and voting mechanics.
  • Three NXP PowerQUICC II series processors executing application logic in lock-step synchronization.
  • Support for hot replacement in Companion Slot active/standby configurations without program re-loading.
  • Integrated IRIG-B002 (RS422/485) and IRIG-B122 (1 kHz modulated) time synchronization inputs.
  • Front panel RS232 serial diagnostic port and status/diagnostic LED indicators.
  • Active and Standby processor fault and fail relay contact outputs.
  • IEC 61131-3 programming language support via the system toolset.

Applications

  • Safety Instrumented Systems (SIS)
  • Emergency Shutdown Systems (ESD)
  • Fire and Gas Detection Systems (F&G)
  • Critical Process Control Systems
  • Burner Management Systems (BMS)

Technical Specifications

Parameter Specification
Manufacturer ICS Triplex / Rockwell Automation
Model T8111
Backplane (IMB) Supply 20 Vdc to 32 Vdc
Power Dissipation 30 W
Module Location T8100 Processor Slot
Serial Communications Ports 3 Rear Serial Ports (RS-422/485), 1 Diagnostics Serial Port (RS-232)
Time Sync Ports 1 IRIG-B002, 1 IRIG-B122
Relay Outputs 1 Fault Relay (0.5 A @ 24 Vdc), 1 Fail Relay (0.5 A @ 24 Vdc)
Baud Rates 9600 baud to 115200 baud
Communications Protocols Modbus RTU (via Rear Serial Ports)
Maximum Application Size 960 KB
Retained Variable Storage 4 KB total (1 byte per Boolean, 4 bytes per Analogue, 5 bytes per Timer)
SOE Buffer 1000 events
Operating Temperature 0 degC to 60 degC (32 degF to 140 degF)
Storage Temperature -25 degC to 70 degC (-13 degF to 158 degF)
Relative Humidity 10%-95%, non-condensing
Dimensions (H x W x D) 266 mm x 93 mm x 303 mm (10.5 in x 3.6 in x 12.0 in)
Weight 1.89 kg (4.17 lb)

Connections/Interfaces

Connector Pin Function
PL1 Row A Pin 2 Fault relay (NC)
PL1 Row A Pin 4 Fault relay (COM)
PL1 Row A Pin 6 Fault relay (NO)
PL1 Row A Pin 22, 24, 26 Chassis GND
PL1 Row A Pin 28 Serial Port 3 B RX/TX
PL1 Row A Pin 30 Serial Port 3 A RX/TX
PL1 Row A Pin 32 24 V Return
PL1 Row C Pin 6 0 V Port 1
PL1 Row C Pin 8 Serial Port 1 B
PL1 Row C Pin 10 Serial Port 1 A
PL1 Row C Pin 12 0 V Port 2
PL1 Row C Pin 14 Serial Port 2 B TX
PL1 Row C Pin 16 Serial Port 2 A TX
PL1 Row C Pin 18 Serial Port 2 B RX/TX
PL1 Row C Pin 20 Serial Port 2 A RX/TX
PL1 Row C Pin 22 0 V Port 3
PL1 Row C Pin 24 Serial Port 3 B TX
PL1 Row C Pin 26 Serial Port 3 A TX
PL1 Row C Pin 28 24 V PSU 1 LV Warning
PL1 Row C Pin 30 24 V PSU 2 LV Warning
PL1 Row C Pin 32 24 V Return
PL1 Row E Pin 2 Fail relay (NC)
PL1 Row E Pin 4 Fail relay (COM)
PL1 Row E Pin 6 Fail relay (NO)
PL1 Row E Pin 10 IRIG-B122+
PL1 Row E Pin 12 IRIG-B122-
PL1 Row E Pin 18 IRIG-B002-
PL1 Row E Pin 20 IRIG-B002+
PL1 Row E Pin 22, 24, 26 Chassis GND
PL1 Row E Pin 28 24V PSU 1 Fail Shutdown
PL1 Row E Pin 30 24V PSU 2 Fail Shutdown
PL1 Row E Pin 32 24 V Return

Installation Guidelines

  • Visual Inspection: Inspect the module housing and rear I/O connectors for damaged or bent pins prior to installation. Do not attempt to straighten bent pins.
  • Electrostatic Discharge Safety: Static handling precautions must be observed. Do not touch exposed connector pins or attempt to open the module housing.
  • Insertion Procedure: Ensure the rear adapter unit is installed. Release top and bottom ejector tabs fully using the release key, slide the module smoothly into its designated chassis slot, and press the fascia until the ejectors click locked.
  • Key Switch Positions: Set the maintenance enable keyswitch to 'Run' to lock memory during standard execution, or 'Maintain' to enable application downloads from the workstation.

Compliance and Certifications

  • Certified to IEC 61508 SIL 3
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How does the module handle real-time clock retention when powered down?
The real-time clock uses capacitor energy storage providing up to 8 hours of backup retention time when main power is off.
What happens if one of the three processor slices develops a fault during operation?
The device logs the fault and continues 2003 voting operation. In an active and standby setup, processing automatically switches to the standby module.
What port connection is used for front panel diagnostic and configuration access?
The front panel is equipped with an RS232 serial diagnostic port designed to interface with an engineering workstation.
Reviews

T8111

Stock & lead time on request

Call
1 su 2

ICS Triplex T8111 Trusted TMR Processor Module

Only 15 item(s) left in stock
  • Manufacturer: ICS Triplex

  • Product No.: T8111

  • Country of origin:Mexico

  • Product Type: Processor Module

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 1890g

  • Dimensions: 93 mm x 266 mm x 303 mm (W x H x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

Quantità
Visualizza dettagli completi

Product Description

Description

ICS Triplex T8111 is a fault-tolerant main processing component designed for the Trusted system architecture. Operating in a Triple Modular Redundant (TMR) lock-step configuration across three independent Processor fault containment regions (FCRs), the T8111 executes user-defined application programs, performs system monitoring, and manages I/O data exchanges across the triplicated Inter-Module Bus. The module integrates two configurable RS422/485 serial ports, one dedicated RS485 2-wire serial port, an RS232 front panel diagnostic interface, and built-in IRIG-B time synchronization capabilities. The ICS Triplex T8111 is designed for critical safety instrumented functions and process control applications requiring high availability and fault isolation.

Features

  • Triple Modular Redundant (TMR) architecture with Hardware Implemented Fault Tolerant (HIFT) clock and voting mechanics.
  • Three NXP PowerQUICC II series processors executing application logic in lock-step synchronization.
  • Support for hot replacement in Companion Slot active/standby configurations without program re-loading.
  • Integrated IRIG-B002 (RS422/485) and IRIG-B122 (1 kHz modulated) time synchronization inputs.
  • Front panel RS232 serial diagnostic port and status/diagnostic LED indicators.
  • Active and Standby processor fault and fail relay contact outputs.
  • IEC 61131-3 programming language support via the system toolset.

Applications

  • Safety Instrumented Systems (SIS)
  • Emergency Shutdown Systems (ESD)
  • Fire and Gas Detection Systems (F&G)
  • Critical Process Control Systems
  • Burner Management Systems (BMS)

Technical Specifications

Parameter Specification
Manufacturer ICS Triplex / Rockwell Automation
Model T8111
Backplane (IMB) Supply 20 Vdc to 32 Vdc
Power Dissipation 30 W
Module Location T8100 Processor Slot
Serial Communications Ports 3 Rear Serial Ports (RS-422/485), 1 Diagnostics Serial Port (RS-232)
Time Sync Ports 1 IRIG-B002, 1 IRIG-B122
Relay Outputs 1 Fault Relay (0.5 A @ 24 Vdc), 1 Fail Relay (0.5 A @ 24 Vdc)
Baud Rates 9600 baud to 115200 baud
Communications Protocols Modbus RTU (via Rear Serial Ports)
Maximum Application Size 960 KB
Retained Variable Storage 4 KB total (1 byte per Boolean, 4 bytes per Analogue, 5 bytes per Timer)
SOE Buffer 1000 events
Operating Temperature 0 degC to 60 degC (32 degF to 140 degF)
Storage Temperature -25 degC to 70 degC (-13 degF to 158 degF)
Relative Humidity 10%-95%, non-condensing
Dimensions (H x W x D) 266 mm x 93 mm x 303 mm (10.5 in x 3.6 in x 12.0 in)
Weight 1.89 kg (4.17 lb)

Connections/Interfaces

Connector Pin Function
PL1 Row A Pin 2 Fault relay (NC)
PL1 Row A Pin 4 Fault relay (COM)
PL1 Row A Pin 6 Fault relay (NO)
PL1 Row A Pin 22, 24, 26 Chassis GND
PL1 Row A Pin 28 Serial Port 3 B RX/TX
PL1 Row A Pin 30 Serial Port 3 A RX/TX
PL1 Row A Pin 32 24 V Return
PL1 Row C Pin 6 0 V Port 1
PL1 Row C Pin 8 Serial Port 1 B
PL1 Row C Pin 10 Serial Port 1 A
PL1 Row C Pin 12 0 V Port 2
PL1 Row C Pin 14 Serial Port 2 B TX
PL1 Row C Pin 16 Serial Port 2 A TX
PL1 Row C Pin 18 Serial Port 2 B RX/TX
PL1 Row C Pin 20 Serial Port 2 A RX/TX
PL1 Row C Pin 22 0 V Port 3
PL1 Row C Pin 24 Serial Port 3 B TX
PL1 Row C Pin 26 Serial Port 3 A TX
PL1 Row C Pin 28 24 V PSU 1 LV Warning
PL1 Row C Pin 30 24 V PSU 2 LV Warning
PL1 Row C Pin 32 24 V Return
PL1 Row E Pin 2 Fail relay (NC)
PL1 Row E Pin 4 Fail relay (COM)
PL1 Row E Pin 6 Fail relay (NO)
PL1 Row E Pin 10 IRIG-B122+
PL1 Row E Pin 12 IRIG-B122-
PL1 Row E Pin 18 IRIG-B002-
PL1 Row E Pin 20 IRIG-B002+
PL1 Row E Pin 22, 24, 26 Chassis GND
PL1 Row E Pin 28 24V PSU 1 Fail Shutdown
PL1 Row E Pin 30 24V PSU 2 Fail Shutdown
PL1 Row E Pin 32 24 V Return

Installation Guidelines

  • Visual Inspection: Inspect the module housing and rear I/O connectors for damaged or bent pins prior to installation. Do not attempt to straighten bent pins.
  • Electrostatic Discharge Safety: Static handling precautions must be observed. Do not touch exposed connector pins or attempt to open the module housing.
  • Insertion Procedure: Ensure the rear adapter unit is installed. Release top and bottom ejector tabs fully using the release key, slide the module smoothly into its designated chassis slot, and press the fascia until the ejectors click locked.
  • Key Switch Positions: Set the maintenance enable keyswitch to 'Run' to lock memory during standard execution, or 'Maintain' to enable application downloads from the workstation.

Compliance and Certifications

  • Certified to IEC 61508 SIL 3

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ICS Triplex T8111 Trusted TMR Processor Module

How does the module handle real-time clock retention when powered down?

The real-time clock uses capacitor energy storage providing up to 8 hours of backup retention time when main power is off.

What happens if one of the three processor slices develops a fault during operation?

The device logs the fault and continues 2003 voting operation. In an active and standby setup, processing automatically switches to the standby module.

What port connection is used for front panel diagnostic and configuration access?

The front panel is equipped with an RS232 serial diagnostic port designed to interface with an engineering workstation.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
