Omron CP1H-X40DR-A CP1H Series PLC CPU Unit

SKU CP1H-X40DR-A

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CP1H-X40DR-A
  • Origin Japan
  • Product Type: PLC CPU Units
  • Payment: T/T, Western Union
  • Weight: 0.77 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CP1H Series PLC CPU Units
Quantità
Call sales Contact

Product Description

Description

Designed for compact, multi-axis positioning and robust machine control, the Omron CP1H-X40DR-A functions as a highly integrated programmable logic controller (PLC) CPU unit within the CP1H series. This high-speed controller combines a compact form factor with the functional capabilities of a modular PLC, featuring built-in high-speed counter inputs and analog option board expansion capability to streamline complex automation tasks.

The unit features 24 integrated DC inputs and 16 robust relay outputs, making it ideal for systems requiring reliable mechanical switching and isolation. With a generous program capacity of 20K steps, it provides the processing depth required for intricate industrial sequencing, closed-loop positioning, and communication management across automated networks.

Features

  • Equipped with a wide-range AC power supply (100 to 240 VAC).
  • Provides 24 VDC inputs (24 points) and relay outputs (16 points) for direct device actuation.
  • Features four high-speed counter inputs operating at 100 kHz for high-precision feedback and encoder tracking.
  • Offers 20K steps of program memory and 32K words of data memory for extensive control logic.
  • Includes two built-in option slots for adding optional RS-232C, RS-422A/485, or Ethernet communication boards.
  • Integrated USB 1.1 port for direct programming, monitoring, and debugging.

Applications

  • Multi-axis positioning systems and packaging machinery.
  • Conveyor systems and material handling systems.
  • Pumping control panels and water distribution stations.
  • Textile processing machines and manufacturing assembly lines.

Technical Specifications

Manufacturer Omron
Model / Part Number CP1H-X40DR-A
Series CP1H Series
Power Supply Voltage 100 to 240 VAC, 50/60 Hz
Input Points 24 points (24 VDC)
Output Points 16 points
Output Type Relay
Program Capacity 20K steps
Data Memory Capacity 32K words
High-Speed Counters 100 kHz, 4 axes
Built-in Ports USB (Type B)
Option Board Slots 2 slots
Weight 0.77 kg

Installation Guidelines

  • Mounting: Mount the unit securely on a 35 mm DIN rail or directly to a flat panel using the integrated mounting screw holes.
  • Ventilation: Provide a minimum of 50 mm of clearance above and below the unit, and 10 mm of clearance on each side to ensure proper convective cooling.
  • Grounding: Connect the functional ground (LG) and protective ground (GR) terminals directly to an independent ground electrode of 100 ohms or less.
  • Wiring: Always separate high-voltage AC power lines from low-voltage DC input/output and signal lines to prevent electrical noise interference.

Compliance and Certifications

  • CE
  • cULus (UC1)
  • NK
  • L (Lloyd's Register)
