Precision thermal loop management is achieved through the Omron E5CC-CX3A5M-004, a compact 48 x 48 mm (1/16 DIN) digital temperature controller engineered for high-speed, stable PID execution. Featuring a high-contrast white LCD display with 15.2 mm character height, this controller ensures clear process value (PV) visibility even in low-light industrial environments. It supports high-speed sampling at 50 ms, allowing immediate response to thermal fluctuations in demanding closed-loop systems.
The unit features a universal input structure, allowing seamless connection of various thermocouples, RTDs, or analog voltage/current sensors without requiring hardware modifications. It is equipped with a linear current control output, three auxiliary outputs, and an integrated RS-485 communications interface, making it an excellent node for distributed control architectures using PLC or SCADA supervisory systems.
| Omron |
| E5CC-CX3A5M-004 |
| E5CC Series (48 x 48 mm) |
| 100 to 240 VAC, 50/60 Hz |
| 85% to 110% of rated voltage |
| Max. 5.2 VA (100 to 240 VAC) |
| Universal input (Thermocouple, RTD, Analog current/voltage) |
| Linear current output (4 to 20 mA DC / 0 to 20 mA DC) |
| None |
| 3 relay outputs (SPST-NO, sharing one common line) |
| RS-485 (2-wire, half-duplex) |
| 2 contact inputs |
| Screw terminals (with terminal cover) |
| Thermocouple: +/-0.3% of PV; RTD: +/-0.2% of PV; Analog: +/-0.2% FS |
| -10 to 55 degC (with no condensation or icing) |
| 25% to 85% RH |
| 0.13 kg |
| Terminal Group | Function Description |
|---|---|
| Power Terminals | 100 to 240 VAC line input |
| Control Output 1 | Linear current output terminals |
| Auxiliary Outputs 1, 2, 3 | Three outputs sharing a single common terminal |
| Sensor Input Terminals | Configurable wiring for RTD (A, B, B), Thermocouple (+, -), or Analog input |
| RS-485 Communication Port | Two-wire communication connections (A and B) |
| Event Inputs 1 and 2 | No-voltage digital contacts |
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: E5CC-CX3A5M-004
Country of origin:Japan
Product Type: Digital Temperature Controllers
Payment: T/T, Western Union
Weight: 130g
Shipping port: Xiamen
Warranty: 12 months
