Description

Designed for industrial machinery safeguarding, the Omron F3SG-4RA0905-25-01TS safety light curtain provides reliable hand and arm protection in high-risk automation environments. This optical barrier utilizes a multi-beam photoelectric sensor array to monitor designated access points, executing a rapid stop signal to protected machinery when the sensing field is interrupted. Featuring robust physical construction and reliable optical performance, it ensures continuous operator safety and seamless integration with industrial safety control networks.

Features

• Provides effective hand and arm protection with a 905 mm protective height.
• Equipped with 44 optical beams to maintain high-resolution object detection.
• Fast response performance with a 13 ms ON-to-OFF response time.
• Low-draw power configuration requiring only 50 mA for the emitter and 80 mA for the receiver.
• Rigid housing construction designed to withstand industrial physical stresses and vibration.

Applications

• Metalworking presses, stamping machinery, and shearing equipment.
• Robotic assembly lines and work cells.
• Automated packaging and material handling systems.
• Machine tool loading and unloading stations.

Technical Specifications

Installation Guidelines

• Ensure precise mechanical alignment between the emitter and the receiver units before finalizing mount placement.
• Calculate and observe the minimum safety distance from the hazardous zone in accordance with regional safety standards (such as ISO 13855).
• Securely ground the mounting brackets and use high-quality shielded cabling to mitigate electromagnetic interference.
• Regularly inspect and clean the optical windows using non-abrasive, static-free materials to maintain optimal signal strength.
