G9SX-ADA222-T15-RT

Omron

Omron G9SX-ADA222-T15-RT G9SX Flexible Safety Unit

SKU G9SX-ADA222-T15-RT

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: G9SX-ADA222-T15-RT
  • Origin Japan
  • Product Type: Safety Relays
  • Payment: T/T, Western Union
  • Weight: 0.2 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

G9SX Safety Relays
Quantità
Call sales Contact

Product Description

Description

Engineered for complex machinery safety circuits, the Omron G9SX-ADA222-T15-RT is a high-performance flexible safety unit configured as an advanced logic module. This device provides dual-channel safety monitoring with a combination of instantaneous and off-delayed solid-state safety outputs. Designed to simplify safety system integration, it allows logical AND connections across multiple G9SX units, enabling safety system expansion without the overhead of a dedicated safety PLC. Built with robust screw terminals, this unit offers reliable performance in environments subject to industrial vibration.

Features

  • Advanced safety unit functionality supporting logical AND connection for modular safety distribution.
  • Features 2 instantaneous semiconductor safety outputs and 2 off-delayed semiconductor safety outputs.
  • Equipped with 2 auxiliary transistor outputs for diagnostic status monitoring.
  • Selectable off-delay configuration with a maximum off-delay time of 15 seconds.
  • Solid-state outputs use P-channel MOS FET transistors for high durability and maintenance-free operation.
  • Screw terminal block design for secure, high-retention wiring connections.

Applications

  • Emergency stop systems in automotive assembly lines.
  • Safety light curtain and interlock switch monitoring in automated packaging machinery.
  • Controlled deceleration and safety stop sequencing for robotic cells.
  • Distributed safety zone control in material handling systems.

Technical Specifications

ManufacturerPart Number / ModelSeriesProduct TypeRated Supply VoltageOperating Voltage RangeRated Power ConsumptionSafety Input VoltageSafety Input ImpedanceInstantaneous Safety OutputsOFF-delayed Safety OutputsMax. OFF-delay TimeAuxiliary OutputsSafety Output Load Current (<= 2 outputs)Safety Output Load Current (>= 3 outputs)Terminal Block TypeVibration ResistanceWeight
Omron
G9SX-ADA222-T15-RT
G9SX
Flexible Safety Unit (Advanced Unit)
24 VDC
-15% to 10% of rated supply voltage
4 W max.
20.4 VDC to 26.4 VDC
Approx. 2.8 kOhm
2 P-channel MOS FET outputs
2 P-channel MOS FET outputs
15 s
2 PNP transistor outputs (100 mA max. load)
1 A DC max.
0.8 A DC max.
Screw terminals
10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
0.2 kg

Installation Guidelines

  • Mount the safety unit on a standard 35 mm DIN rail inside a control cabinet rated IP54 or higher.
  • Provide a minimum clearance of 5 mm on the left and right sides of the unit to ensure adequate heat dissipation.
  • Ensure that the 24 VDC external power supply meets SELV/PELV specifications to maintain correct electrical isolation.
  • Route safety signal input lines away from high-voltage cables and variable frequency drive outputs to minimize electromagnetic noise coupling.
Shipping &amp; Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the maximum off-delay setting for the G9SX-ADA222-T15-RT?
The G9SX-ADA222-T15-RT supports a configurable maximum off-delay safety output time of 15 seconds.
What type of connection interface does this Omron safety unit feature?
This module features screw terminal blocks for secure and vibration-resistant wiring connections, indicated by the 'RT' suffix.
How does output current capability scale with active safety outputs?
When using 2 or fewer safety outputs, the maximum load current is 1 A DC. When using 3 or more safety outputs, the maximum load current is reduced to 0.8 A DC.
What is the rated operating voltage range for this module?
The module has a rated supply voltage of 24 VDC, with an acceptable operating voltage range of -15% to 10% (20.4 VDC to 26.4 VDC).
Reviews

More from this brand

Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
NA5-12W101S-V1Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
Omron XWT-ID16 16-Point Digital Input Expansion Module
XWT-ID16Omron XWT-ID16 16-Point Digital Input Expansion Module
Omron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
G3PE-225B-3NOmron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit
NX-ECC202Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit

G9SX-ADA222-T15-RT

Stock &amp; lead time on request

Call
  • G9SX-ADA222-T15-RT
1 1

Omron G9SX-ADA222-T15-RT G9SX Flexible Safety Unit

Only 8 item(s) left in stock

  • Manufacturer: Omron

  • Product No.: G9SX-ADA222-T15-RT

  • Country of origin:Japan

  • Product Type: Safety Relays

  • Payment: T/T, Western Union

  • Weight: 200g

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Engineered for complex machinery safety circuits, the Omron G9SX-ADA222-T15-RT is a high-performance flexible safety unit configured as an advanced logic module. This device provides dual-channel safety monitoring with a combination of instantaneous and off-delayed solid-state safety outputs. Designed to simplify safety system integration, it allows logical AND connections across multiple G9SX units, enabling safety system expansion without the overhead of a dedicated safety PLC. Built with robust screw terminals, this unit offers reliable performance in environments subject to industrial vibration.

Features

  • Advanced safety unit functionality supporting logical AND connection for modular safety distribution.
  • Features 2 instantaneous semiconductor safety outputs and 2 off-delayed semiconductor safety outputs.
  • Equipped with 2 auxiliary transistor outputs for diagnostic status monitoring.
  • Selectable off-delay configuration with a maximum off-delay time of 15 seconds.
  • Solid-state outputs use P-channel MOS FET transistors for high durability and maintenance-free operation.
  • Screw terminal block design for secure, high-retention wiring connections.

Applications

  • Emergency stop systems in automotive assembly lines.
  • Safety light curtain and interlock switch monitoring in automated packaging machinery.
  • Controlled deceleration and safety stop sequencing for robotic cells.
  • Distributed safety zone control in material handling systems.

Technical Specifications

ManufacturerPart Number / ModelSeriesProduct TypeRated Supply VoltageOperating Voltage RangeRated Power ConsumptionSafety Input VoltageSafety Input ImpedanceInstantaneous Safety OutputsOFF-delayed Safety OutputsMax. OFF-delay TimeAuxiliary OutputsSafety Output Load Current (<= 2 outputs)Safety Output Load Current (>= 3 outputs)Terminal Block TypeVibration ResistanceWeight
Omron
G9SX-ADA222-T15-RT
G9SX
Flexible Safety Unit (Advanced Unit)
24 VDC
-15% to 10% of rated supply voltage
4 W max.
20.4 VDC to 26.4 VDC
Approx. 2.8 kOhm
2 P-channel MOS FET outputs
2 P-channel MOS FET outputs
15 s
2 PNP transistor outputs (100 mA max. load)
1 A DC max.
0.8 A DC max.
Screw terminals
10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
0.2 kg

Installation Guidelines

  • Mount the safety unit on a standard 35 mm DIN rail inside a control cabinet rated IP54 or higher.
  • Provide a minimum clearance of 5 mm on the left and right sides of the unit to ensure adequate heat dissipation.
  • Ensure that the 24 VDC external power supply meets SELV/PELV specifications to maintain correct electrical isolation.
  • Route safety signal input lines away from high-voltage cables and variable frequency drive outputs to minimize electromagnetic noise coupling.
Key Features:
#G9SX #Safety Relays

What is the maximum off-delay setting for the G9SX-ADA222-T15-RT?
The G9SX-ADA222-T15-RT supports a configurable maximum off-delay safety output time of 15 seconds.

What type of connection interface does this Omron safety unit feature?
This module features screw terminal blocks for secure and vibration-resistant wiring connections, indicated by the 'RT' suffix.

How does output current capability scale with active safety outputs?
When using 2 or fewer safety outputs, the maximum load current is 1 A DC. When using 3 or more safety outputs, the maximum load current is reduced to 0.8 A DC.

What is the rated operating voltage range for this module?
The module has a rated supply voltage of 24 VDC, with an acceptable operating voltage range of -15% to 10% (20.4 VDC to 26.4 VDC).

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
