Direct human-machine interface interaction is established through the Omron NS5-MQ11-V2, a reliable monochrome terminal engineered for integration within the Omron NS Series architecture. This unit provides a highly functional visual interface for machine-level monitoring and control, housing a robust display in a durable panel-mount form factor. Configured with dual RS-232C ports, it coordinates seamless communication with host PLCs, temperature controllers, and auxiliary devices. Designed for operational longevity, this model features an ivory bezel that integrates cleanly with classic industrial control cabinets.
| Manufacturer | Omron |
| Model Reference | NS5-MQ11-V2 |
| Series | NS Series |
| Display Type | STN Monochrome LCD |
| Display Size | 5.7 inches |
| Resolution | 320 x 240 pixels (QVGA) |
| Input Voltage | 24 VDC (Acceptable range: 20.4 to 27.6 VDC) |
| Power Consumption | 15 Watts maximum |
| Serial Communications | 2x RS-232C Ports |
| USB Ports | 1x USB Type-B Slave (USB 1.1) |
| Case Color | Ivory |
| Operating Temperature | 0 to 50 degC |
| Front Panel Protection | IP65F equivalent |
| Country of Origin | Japan |
| Shipping Weight (Calculated) | 1.5 kg |
| Package Dimensions (Calculated) | 24.5 cm x 19.2 cm x 8.5 cm |
| Port Reference | Connector Type | Functional Assignment / Signal Mapping |
|---|---|---|
| Serial Port A | D-Sub 9-pin Female | Host Link / NT Link RS-232C serial connection to PLC CPU. |
| Serial Port B | D-Sub 9-pin Female | Auxiliary serial communications (RS-232C), peripheral devices, or temperature controllers. |
| USB Tool Port | USB Type-B (Slave) | Dedicated interface for high-speed programming, screen downloads, and online system debugging. |
| Power Input Terminal | M3.5 Screw Terminal Block | 24 VDC Power Input along with functional ground (FG) terminal for noise abatement. |
The "V2" suffix represents upgraded internal processing and expanded compatibility with newer runtime versions compared to legacy V1 variants. Note that the NS5-MQ11-V2 (Ivory bezel) is chemically and structurally identical in internal operation to the NS5-MQ11B-V2 (Black bezel), permitting direct drop-in substitution when bezel aesthetics are not critical. Software configuration projects built in CX-Designer can target either color variant without modification.
Because this unit utilizes a monochrome STN LCD, viewing angles and response latency can be more pronounced compared to modern TFT equivalents. When designing HMI screens, maintain high-contrast graphic layouts (solid black/white configurations rather than gradient shades) to preserve visibility in direct plant floor lighting. Ensure the rear ventilation slot is unblocked; operation inside enclosures exceeding 50 degC will significantly accelerate CCFL backlight degradation.
To protect against communication time-outs and localized ground loop disruption, dedicated 24 VDC supply routing is recommended. Keep serial RS-232C lines isolated from high-voltage motor starters and variable frequency drive cables. Always verify the functional ground terminal is tied back to a solid low-impedance earth connection using a wire size of at least 2.0 mm².
Isolate and verify de-energization of the primary power supply source before working on the 24 VDC terminals. Do not service the power connector, change the system configuration, or adjust wiring while voltage is applied to avoid physical shock or severe control system damage.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: NS5-MQ11-V2
Country of origin:Japan
Product Type: HMI Programmable Terminals
Payment: T/T, Western Union
Weight: 8000g
Dimensions: 24.5 cm x 19.2 cm x 8.5 cm
Shipping port: Xiamen
Warranty: 12 months
