Delivering precise voltage control within the Sysmac automation platform, the Omron NX-DA2603 analog output unit provides reliable high-density analog signal generation in a space-saving 12 mm form factor. Designed for seamless integration with NX-series CPU Units or EtherCAT Coupler Units, this module features a 2-point output capacity operating over a -10 to +10 V range. Utilizing the optimized Free-Run refreshing method, the module ensures steady signal performance across continuous processing demands while maintaining robust galvanic isolation from the system bus to protect sensitive upstream logic controllers.
| Parameter | Specification Value |
|---|---|
| Manufacturer | Omron |
| Model / Article Number | NX-DA2603 |
| Series | Sysmac NX Series |
| Output Points | 2 points |
| Output Range | -10 to +10 V |
| I/O Refreshing Method | Free-Run refreshing |
| Isolation Method | Between input and NX bus: Power = Transformer, Signal = Digital isolator (No channel-to-channel isolation) |
| Insulation Resistance | 20 MOhm minimum between isolated circuits (at 100 VDC) |
| Dielectric Strength | 510 VAC between isolated circuits for 1 minute (leakage current: 5 mA max) |
| I/O Power Supply Method | Supply from the NX bus |
| Dimensions (W x D x H) | 12 mm x 71 mm x 100 mm (Calculated) |
| Shipping Weight (Calculated) | 0.25 kg |
CRITICAL WARNING: electrical shock hazard
Ensure the main power supplies to both the NX-bus and the field devices are completely de-energized before mounting, removing, or wiring the module. Failure to observe this protocol can cause irreversible damage to the internal logic components or unexpected field device behavior.
Align the module side-connecting guides with the adjacent NX unit on the DIN rail track.
Slide the NX-DA2603 firmly onto the DIN rail until you hear an audible click, indicating the bus connector is fully locked into position.
Wire signal cables using ferrules into the Push-in Plus terminals. Secure signal shielding to a functional ground bar to minimize high-frequency noise interference.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: NX-DA2603
Country of origin:Japan
Product Type: Analog Output Modules
Payment: T/T, Western Union
Weight: 2000g
Dimensions: 12 mm x 71 mm x 100 mm
Shipping port: Xiamen
Warranty: 12 months
Delivering precise voltage control within the Sysmac automation platform, the Omron NX-DA2603 analog output unit provides reliable high-density analog signal generation in a space-saving 12 mm form factor. Designed for seamless integration with NX-series CPU Units or EtherCAT Coupler Units, this module features a 2-point output capacity operating over a -10 to +10 V range. Utilizing the optimized Free-Run refreshing method, the module ensures steady signal performance across continuous processing demands while maintaining robust galvanic isolation from the system bus to protect sensitive upstream logic controllers.
| Parameter | Specification Value |
|---|---|
| Manufacturer | Omron |
| Model / Article Number | NX-DA2603 |
| Series | Sysmac NX Series |
| Output Points | 2 points |
| Output Range | -10 to +10 V |
| I/O Refreshing Method | Free-Run refreshing |
| Isolation Method | Between input and NX bus: Power = Transformer, Signal = Digital isolator (No channel-to-channel isolation) |
| Insulation Resistance | 20 MOhm minimum between isolated circuits (at 100 VDC) |
| Dielectric Strength | 510 VAC between isolated circuits for 1 minute (leakage current: 5 mA max) |
| I/O Power Supply Method | Supply from the NX bus |
| Dimensions (W x D x H) | 12 mm x 71 mm x 100 mm (Calculated) |
| Shipping Weight (Calculated) | 0.25 kg |
CRITICAL WARNING: electrical shock hazard
Ensure the main power supplies to both the NX-bus and the field devices are completely de-energized before mounting, removing, or wiring the module. Failure to observe this protocol can cause irreversible damage to the internal logic components or unexpected field device behavior.
Align the module side-connecting guides with the adjacent NX unit on the DIN rail track.
Slide the NX-DA2603 firmly onto the DIN rail until you hear an audible click, indicating the bus connector is fully locked into position.
Wire signal cables using ferrules into the Push-in Plus terminals. Secure signal shielding to a functional ground bar to minimize high-frequency noise interference.
