NX-ECC201

Omron

Omron NX-ECC201 EtherCAT Coupler Unit

SKU NX-ECC201

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX-ECC201
  • Origin Japan
  • Product Type: EtherCAT Coupler Unit
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EtherCAT Couplers
Quantità
Call sales Contact

Product Description

Description

The NX-ECC201 is a high-performance EtherCAT Coupler Unit designed to serve as the gateway between an EtherCAT network and the Omron NX-series I/O family. This unit enables seamless, high-speed communication between a master controller (such as an Omron NJ/NX machine automation controller) and distributed I/O modules, allowing for modular, scalable machine architectures.

With a compact width of 46 mm, the NX-ECC201 manages the local power supply and communication for connected NX units, ensuring synchronized data exchange across the EtherCAT network. It supports a rated voltage of 24 VDC for the unit power supply and provides robust power distribution for connected I/O, supporting up to 4A for the I/O power supply.

Features

  • Network Protocol: EtherCAT (high-speed, real-time industrial Ethernet)
  • Integration: Central hub for modular NX-series I/O modules
  • Power Management: Manages local unit power (24 VDC) and distributed I/O power (5–24 VDC, 4A max)
  • Synchronization: Supports high-speed, deterministic data exchange for motion and process control
  • Design: Slim 46 mm width for space-efficient cabinet mounting

Applications

  • Distributed I/O systems for multi-axis motion control
  • High-speed manufacturing and packaging lines
  • Integrated plant-wide data acquisition
  • Modular machine designs requiring easy expansion

Technical Specifications

Feature Specification
Manufacturer Omron
Model NX-ECC201
Product Type EtherCAT Coupler Unit
Width 46 mm
NX Unit Power Supply 24 VDC (10 W max)
I/O Power Supply 5–24 VDC (4A max)
Weight 0.17 kg

Installation Guidelines

  • Mounting: Snap the coupler onto a standard 35 mm DIN rail. Ensure the connection pins on the side are aligned to facilitate communication with the first NX-series I/O module.
  • Network Wiring: Use shielded Category 5e (or higher) Ethernet cables to ensure reliable communication in high-EMI industrial environments.
  • Power Supply: Use a dedicated, stable 24 VDC power supply for the NX Unit and ensure the I/O power supply meets the specific requirements of the connected sensors and actuators.
  • Configuration: Integrate the coupler into your EtherCAT network using the Sysmac Studio software to map I/O data and ensure the bus configuration is validated.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary role of the NX-ECC201?
The NX-ECC201 functions as a communications gateway, connecting the EtherCAT network to a modular stack of Omron NX-series I/O modules.
What power capabilities does this coupler provide?
It provides power to the connected NX-series I/O units (10W max) and can handle up to 4A for the I/O power supply circuit.
Which software is required to configure the NX-ECC201?
Omron's Sysmac Studio software is typically used to configure, map, and troubleshoot the EtherCAT coupler and its connected I/O units.
