Description

The ATV212HD18M3X is an Altivar 212 frequency converter rated at 18.5 kW for 240 V three-phase motor control applications. Manufactured by Schneider Electric, this variable frequency drive is engineered to regulate the speed and torque of AC motors, optimizing energy efficiency and operational control in commercial and industrial fluid management systems.

The ATV212HD18M3X features a compact physical profile with dimensions of 30 x 39 x 28 cm and an operating weight of 11.32 kg, designed with an IP21 protection rating and supplied without an integrated EMC filter. As a phase-out lifecycle product, it supports legacy maintenance, direct hardware replacement, and system continuity in established HVAC and pumping installations.

Features

• 18.5 kW power output for three-phase motor control
• 240 V nominal operating voltage compatibility
• IP21 enclosure protection rating for standard indoor environments
• Designed without an integrated EMC filter for specific installation requirements
• Altivar 212 product range compatibility for automated drive systems

Applications

• HVAC ventilation and air handling units
• Industrial and commercial water pumping stations
• Compressor and blower speed regulation
• Building management fluid control systems

Technical Specifications

Installation Guidelines

• Mount the ATV212HD18M3X vertically inside a clean, well-ventilated electrical cabinet or indoor enclosure complying with an IP21 environment.
• Maintain adequate clearance above and below the drive to ensure proper natural convection cooling and prevent thermal overload.
• Verify that the 240 V three-phase power supply matches the electrical ratings of the drive before connecting input power.
• Route motor power cables and low-voltage control wiring separately to minimize electromagnetic interference (EMI).
