Siemens 6AV6643-5CD00-0FA1 SIMATIC MP 277 10.4" Touch Multi Panel

SKU 6AV6643-5CD00-0FA1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6AV6643-5CD00-0FA1
  • Origin Germany
  • Product Type: HMI Touch Panels
  • Barcode: 85371091
  • Payment: T/T, Western Union
  • Weight: 3.34 kg
  • Dimensions: 37.70 x 28.70 x 22.10 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

HMI Multi Panels Simatic HMIs
Quantità
Call sales Contact

Product Description

Description

The Siemens 6AV6643-5CD00-0FA1 is a SIMATIC MP 277 series Human Machine Interface (HMI) designed for machine-level visualization and control. This unit features a 10.4-inch touch screen display and is equipped with non-volatile MRAM (Magnetoresistive RAM). While this specific part number was originally a customer-specific design for FIMA FMC, it is delivered with a standard front panel. As a component of the SIMATIC HMI Multi Panel 270 series, it provides robust operator interface capabilities for various industrial automation systems. Please note this product is designated as a Phase-Out item in the Siemens Product Lifecycle Management (PLM) system.

Features

  • 10.4-inch color touch display for operator interaction
  • Integrated MRAM for data retention
  • Part of the SIMATIC HMI MP 270 series
  • Standard front panel design

Applications

  • Machine control and process visualization
  • Factory automation systems
  • Data logging and recipe management
  • Plant floor operator stations

Technical Specifications

Specification Value
Manufacturer Siemens
Product Series SIMATIC HMI
Product Sub-Range Multi panels 270 series
Model MP 277 10.4" Touch
Order Number / SKU 6AV6643-5CD00-0FA1
Product Type Multi Panel
Display Size 10.4 inch
Input Method Touch Screen
Memory Technology MRAM
PLM Status Phase-Out
Shipping Weight 3.34 kg
Package Dimensions (cm) 37.70 x 28.70 x 22.10 cm
Commodity Code 85371091
ECCN N
Country of Origin Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: Electrical Hazard. Installation must be performed by qualified personnel only. Failure to de-energize equipment before installation can result in severe injury or death. Always follow local Lockout/Tagout (LOTO) procedures.
  1. 1 De-energize System: Before beginning installation, disconnect and lock out all power sources to the control cabinet or panel where the HMI will be installed. Verify the absence of voltage with a properly rated meter.
  2. 2 Prepare Panel Cutout: Ensure the mounting surface is clean, flat, and rigid. Verify that the panel cutout dimensions match the HMI's specifications to ensure a proper seal and secure fit.
  3. 3 Mount the HMI: Insert the HMI into the panel cutout from the front. Secure it from the rear using the provided mounting clips, tightening them evenly to the manufacturer's recommended torque to maintain the IP rating. Do not overtighten.
  4. 4 Connect Cabling: Connect the DC power supply, communication cables (e.g., PROFIBUS, Ethernet), and any other required I/O. Ensure all connectors are fully seated and secured. Route cables away from high-voltage lines to minimize electrical noise.
  5. 5 Grounding: Connect the functional earth (FE) terminal on the HMI to the control cabinet's ground bar using a low-impedance conductor. Proper grounding is essential for noise immunity and operator safety.
