Siemens 6AV7240-0AB07-0PA0 SIMATIC IPC 477D Panel PC

SKU 6AV7240-0AB07-0PA0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7240-0AB07-0PA0
Origin Germany
Product Type: Panel PC
Barcode: 85371098
Payment: T/T, Western Union
Weight: 3.2 kg
Dimensions: 28.0 x 15.0 x 15.0 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

This is a Siemens 6AV7240-0AB07-0PA0, a SIMATIC IPC 477D series Panel PC designed for robust human-machine interface (HMI) and control applications in industrial environments. The unit features a 12-inch touch display for intuitive operator interaction and is powered by an Intel Celeron U827E processor with 2 GB of RAM. It comes equipped with a 240 GB MLC Solid-State Drive (SSD) and is pre-installed with the Windows 7 Ultimate 64-bit operating system. Connectivity is provided through multiple USB ports, an RS-232 serial port, and three Ethernet interfaces, including two Gigabit ports with PROFINET (PN) capability. The device operates on a standard 24 V DC industrial power supply.

Features

12-inch integrated touch display
Intel Celeron U827E processor
2 GB of system memory (RAM)
240 GB Solid-State Drive (MLC) for reliable storage
Pre-installed Microsoft Windows 7 Ultimate (64-bit)
Two Gigabit Ethernet ports for Industrial Ethernet (IE) and PROFINET (PN)
One standard 10/100/1000 Mbps Ethernet port
Four rear-mounted USB ports and one RS-232 serial port
Integrated 24 V DC industrial power supply input

Applications

Process visualization and control
Machine-level data acquisition and logging
Manufacturing Execution Systems (MES) terminals
Factory automation and assembly line control
Building automation systems

Technical Specifications

Specification	Value
Brand	Siemens
Model	6AV7240-0AB07-0PA0
Series	SIMATIC IPC 477D
Product Type	Panel PC
Display	12-inch Touch Display
Processor	Intel Celeron U827E
System Memory (RAM)	2 GB
Storage	240 GB SSD (MLC)
Operating System	Windows 7 Ultimate (64-bit)
Ethernet Ports	2x Gigabit Ethernet (IE/PN), 1x Ethernet (10/100/1000 Mbps)
USB Ports	4x USB (Back)
Serial Port	1x RS-232
Expansion Slots	Without PCIe
Power Supply	24 V DC
Product Lifecycle Status	Phase-Out
Package Dimensions (Calculated)	28.0 x 15.0 x 15.0 cm
Shipping Weight	3.20 kg
Country of Origin	Germany (estimated)

Installation Guidelines

CRITICAL WARNING: Risk of Electric Shock

Installation, modification, or removal of this device must be performed only by qualified electrical personnel. Always de-energize the entire system and apply appropriate Lockout/Tagout (LOTO) procedures before accessing any terminals or internal components. Failure to comply can result in severe injury or death.

1 System De-energization: Before installation, disconnect and lock out all power sources to the control panel or machine where the Panel PC will be installed. Verify the absence of voltage using a properly rated test instrument.
2 Panel Mounting: Prepare the panel cutout according to the manufacturer's dimensional drawings. Secure the Panel PC into the cutout using all provided mounting clamps, ensuring a uniform and tight seal to maintain the specified enclosure rating.
3 Protective Grounding: Connect the chassis ground terminal of the IPC to the main protective earth (PE) bus bar of the enclosure using a low-impedance conductor. A reliable ground connection is critical for safety and noise immunity.
4 Power and I/O Wiring: Connect the 24 V DC power supply, ensuring correct polarity. Connect all communication (Ethernet, USB, RS-232) and peripheral cables. Route signal and power cables separately to minimize electromagnetic interference.
5 System Commissioning: After verifying all connections, remove LOTO devices and re-apply power to the system. Power on the Panel PC and proceed with software configuration and system checks.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What operating system is installed on this Panel PC?

This unit comes pre-installed with Microsoft Windows 7 Ultimate (64-bit).

What is the storage capacity and type?

The device is equipped with a 240 GB standard MLC (Multi-Level Cell) Solid-State Drive (SSD) for storage.

What are the primary network interfaces?

The Panel PC features two Gigabit Ethernet ports compatible with Industrial Ethernet (IE) and PROFINET (PN), plus one standard 10/100/1000 Mbps Ethernet port.

What is the required input power?

This model requires a 24 V DC industrial power supply for operation.

Does this configuration include any SIMATIC software?

No, this specific part number is supplied without any pre-installed SIMATIC software packages.
