Description

The Siemens 6AV7240-3CC10-0HA0 is a SIMATIC IPC 477D industrial Panel PC, featuring a 15-inch touch/key display for human-machine interface applications. This robust industrial computer is equipped with a Core i3-3217UE processor and 4 GB of memory, making it suitable for various automation tasks. It includes an 80 GB standard SSD (MLC) for internal mass storage and supports swappable mass storage without requiring a drive. Connectivity options include four USB ports on the back, one USB port on the front, and two Gigabit Ethernet (IE/PN) ports. Hardware extensions are supported via one RS232 and one PCIe interface. The unit is supplied without an operating system and without SIMATIC software, allowing for flexible integration into existing industrial environments, powered by a 24 V DC industrial power supply.

Features

• 15-inch Touch/Key Display
• Core i3-3217UE Processor
• 4 GB Memory Configuration
• 80 GB Standard SSD (MLC) Internal Mass Storage
• Swappable Mass Storage (replaceable without drive)
• 4x USB (back) + 1x USB (front)
• 2x Gigabit Ethernet (IE/PN) (10/100/1000)
• 1x RS232 and 1x PCIe Hardware Extension
• 24 V DC Industrial Power Supply
• Supplied without Operating System or SIMATIC Software

Applications

The Siemens SIMATIC IPC 477D Panel PC is designed for deployment in a wide range of industrial automation and control applications, including:

• Machine control and visualization
• Process monitoring and data acquisition
• Operator interface stations in manufacturing plants
• Building automation and facility management
• Logistics and material handling systems
• Embedded control solutions requiring a robust HMI

Technical Specifications

Connections / Interfaces

The Panel PC provides the following external interfaces:

• USB Ports: 4 ports located on the back panel, 1 port on the front panel.
• Ethernet Ports: 2x Gbit Ethernet (IE/PN) ports, supporting 10/100/1000 Mbps for industrial network integration.
• Serial Port: 1x RS232 interface for serial communication with peripherals.
• Expansion Slot: 1x PCIe slot for hardware extensions.
• Power Input: 24 V DC industrial power supply connection.

Installation Guidelines

1. Safety First: Ensure all power to the installation area is de-energized before beginning installation. Verify with appropriate lockout/tagout procedures.
2. Mounting: The Panel PC is designed for panel mounting. Ensure adequate space for ventilation and cable routing. Secure the unit using the specified mounting hardware to prevent vibration and ensure stability.
3. Power Connection: Connect the 24 V DC industrial power supply to the designated power input terminals. Observe correct polarity to prevent damage. Ensure the power supply meets the required voltage and current specifications.
4. Grounding: Establish a proper protective earth (PE) connection to the designated grounding terminal on the Panel PC chassis. This is crucial for electrical safety and electromagnetic compatibility (EMC).
5. Network Connections: Connect industrial Ethernet cables to the Gbit Ethernet ports. Use shielded cables for industrial environments to minimize interference.
6. USB and Serial Connections: Connect USB devices and RS232 peripherals as required. Ensure proper cable routing to avoid strain and interference.
7. Ventilation: Maintain proper airflow around the unit. Do not obstruct ventilation openings to prevent overheating.
8. Environmental Considerations: Install the Panel PC in an environment that complies with its specified operating temperature, humidity, and vibration limits.
9. Power Up: After all connections are secure and verified, re-energize the power supply to the Panel PC.
