Description

The Siemens 6AV7241-5BC15-0DA0 is a SIMATIC IPC 477E 15" Touch Panel PC designed for industrial applications. This robust unit features a 15-inch touch display with a resolution of 1280 x 800 pixels. It is equipped with an Intel Core i5-6442EQ processor and 16 GB of RAM, providing reliable performance for demanding industrial control and visualization tasks. The IPC includes a 256 GB ECO SSD for mass storage and comes pre-installed with either Embedded Windows 10 Pro, Windows 11 Pro, or Windows 10 Enterprise 2019 LTSC (64-bit), with multi-language user interface support (EN, DE, FR, IT, ES).

Connectivity options include one front USB port, four rear USB ports, one 10/100/1000 Ethernet port, and three Gigabit Ethernet (IE/PN) ports. It features one PCIe (x4) expansion slot but does not include RS232/RS485 serial interfaces. The unit is powered by a 24 V DC industrial power supply, making it suitable for integration into standard industrial control cabinets and systems.

Features

• 15-inch Touch Display (1280 x 800 resolution)
• Intel Core i5-6442EQ Processor
• 16 GB RAM
• 256 GB ECO SSD Storage
• Operating System Options: Embedded Windows 10 Pro, Windows 11 Pro, or Windows 10 Enterprise 2019 LTSC (64-bit)
• Multi-language User Interface (EN, DE, FR, IT, ES)
• 1x Front USB, 4x Rear USB Ports
• 1x 10/100/1000 Ethernet Port
• 3x Gigabit Ethernet (IE/PN) Ports
• 1x PCIe (x4) Expansion Slot
• 24 V DC Industrial Power Supply
• Designed without RS232/RS485 interfaces
• Without replaceable mass storage
• Without SIMATIC software

Applications

• Machine control and visualization
• Process monitoring and data acquisition
• Human-Machine Interface (HMI) systems
• Industrial data processing and edge computing
• Factory automation and manufacturing execution systems (MES)
• Building automation and infrastructure management

Technical Specifications

Installation Guidelines

1. Safety First: Ensure all power to the installation area is de-energized and locked out before beginning any work.
2. Mounting: Securely mount the Panel PC in a suitable industrial enclosure or panel cutout, ensuring adequate ventilation for heat dissipation.
3. Power Connection: Connect the 24 V DC industrial power supply to the designated terminals, observing correct polarity. Verify the power source meets the specified voltage and current requirements.
4. Grounding: Establish a proper protective earth (PE) connection to the Panel PC chassis to ensure electrical safety and minimize electromagnetic interference.
5. Ethernet Connections: Connect industrial Ethernet cables to the Gbit Ethernet (IE/PN) ports for network integration. Use shielded cables where necessary to maintain signal integrity in noisy industrial environments.
6. USB Peripherals: Connect any required USB peripherals (e.g., keyboard, mouse, barcode scanner) to the available front or rear USB ports.
7. Cable Management: Route all cables neatly and securely, avoiding sharp bends and ensuring they do not interfere with cooling or other components. Separate power and signal cables to reduce interference.
8. Initial Power-Up: After all connections are verified, re-energize the power supply. Observe the system for proper boot-up and functionality.
