Siemens 6AV7861-3AA00-1AA0 SIMATIC FP Flat Panel

SKU 6AV7861-3AA00-1AA0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7861-3AA00-1AA0
Origin Germany
Product Type: Flat Panel
Barcode: 85371091
Payment: T/T, Western Union
Weight: 12.72 kg
Dimensions: 51.00 x 62.50 x 24.00 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6AV7861-3AA00-1AA0 is a SIMATIC Flat Panel 19, a 19-inch TFT screen designed for industrial visualization applications. It features a resolution of 1280x1024 pixels and operates on a 24 V DC power supply. Connectivity is provided via VGA and DVI-D interfaces, and it includes a 1.8 m VGA cable for immediate integration into existing systems. This flat panel is suitable for use as an operator interface or display unit in various industrial environments.

Features

19-inch TFT display
1280x1024 pixel resolution
24 V DC power supply
VGA and DVI-D interfaces
Includes 1.8 m VGA cable

Applications

Industrial visualization systems
Operator interface for control systems
Machine control panels
Process monitoring displays

Technical Specifications

Manufacturer	Siemens
Product Range	SIMATIC
Subrange	FP
Product Type	Flat Panel
Screen Size	19-inch
Display Type	TFT
Resolution	1280x1024 pixels
Power Supply	24 V DC
Interfaces	VGA, DVI-D
Included Cable	VGA cable 1.8 m
Product Phase	Obsolete
Successor Model	6AV7861-3AA00-2AA0
Package Dimensions (Calculated)	51.00 x 62.50 x 24.00 cm
Shipping Weight	12.72 kg
Commodity Code	85371091
Export Control Regulations (ECCN)	EAR99

Installation Guidelines

De-energize System: Before commencing installation, ensure all power to the system and the flat panel's intended mounting location is completely de-energized and locked out.
Mounting: Securely mount the flat panel in its designated enclosure or panel cutout. Ensure proper ventilation space around the unit to prevent overheating.
Power Connection: Connect the 24 V DC power supply to the designated terminals, observing correct polarity. Verify the power source meets the specified voltage requirements.
Video Connection: Connect the appropriate video cable (VGA or DVI-D) from the host system's video output to the corresponding input on the flat panel. The 1.8 m VGA cable is included for convenience.
Grounding: Ensure the flat panel is properly grounded according to local electrical codes and manufacturer recommendations to enhance safety and reduce electromagnetic interference.
Cable Management: Route all cables to prevent strain, sharp bends, and interference with other components. Use cable ties or conduits as necessary.
Power On: After all connections are verified, re-energize the system and the flat panel. Test display functionality and interface communication.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the screen size and resolution of the 6AV7861-3AA00-1AA0?

The flat panel features a 19-inch TFT screen with a resolution of 1280x1024 pixels.

What power supply is required for this SIMATIC Flat Panel?

It requires a 24 V DC power supply for operation.

What video interfaces does the 6AV7861-3AA00-1AA0 support?

The flat panel supports both VGA and DVI-D interfaces, and a 1.8 m VGA cable is included.

Is the Siemens 6AV7861-3AA00-1AA0 still an active product?

No, this product is currently in an obsolete phase.

What is the successor model for this flat panel?

The successor model for the 6AV7861-3AA00-1AA0 is the 6AV7861-3AA00-2AA0.
