Description

The Siemens 6AV7882-0CA20-5BA0 is a SIMATIC IPC277E Nanopanel PC, featuring a 12-inch Touch TFT display. This industrial panel PC is equipped with a Celeron N2807 (2C/2T) processor, 4 GB of RAM, and an 80 GB SSD for reliable operation. It comes pre-installed with Windows 7 Ultimate SP1 (32 bit) with Multi-User Interface (MUI) support for German, English, French, Spanish, and Italian. Connectivity options include two 10/100/1000 Mbps Ethernet RJ45 ports, one Display Port for graphics, one USB 3.0 port, three USB 2.0 ports, and one serial (COM 1) port. It also includes a CFast slot for additional storage or expansion and operates on a 24 V DC power supply. This unit is provided without SIMATIC software.

Features

• 12-inch Touch TFT Display
• Integrated Celeron N2807 (2C/2T) Processor
• 4 GB RAM
• 80 GB Solid State Drive (SSD)
• Pre-installed Windows 7 Ultimate SP1, 32 bit, MUI
• Dual 10/100/1000 Mbps Ethernet RJ45 Ports
• Multiple USB Ports (1x USB 3.0, 3x USB 2.0)
• Single Display Port for Graphics Output
• One Serial (COM 1) Port
• CFast Slot for Expansion
• 24 V DC Power Supply

Applications

The Siemens SIMATIC IPC277E Nanopanel PC is suitable for various industrial automation applications, including:

• Human Machine Interface (HMI) for machine and plant operation
• Data acquisition and visualization in manufacturing environments
• Embedded control and monitoring tasks
• Integration into existing automation systems requiring compact, robust computing
• Process visualization and operational control in harsh industrial settings

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. De-energization: Ensure all power to the installation area is disconnected and locked out before beginning any work.
2. Mounting: Securely mount the Panel PC in a suitable industrial enclosure or panel cutout, ensuring adequate ventilation and clearance for cable connections.
3. Power Connection: Connect the 24 V DC power supply to the designated terminals, observing correct polarity. Verify the power source meets the specified voltage requirements.
4. Grounding: Establish a proper protective earth (PE) connection to the Panel PC chassis to ensure electrical safety and minimize electromagnetic interference.
5. Cable Routing: Route all communication and power cables to prevent strain, interference, and damage. Separate power and signal cables where possible.
6. Peripheral Connections: Connect Ethernet, USB, serial, and display cables to their respective ports as required by the application.
7. Environmental Considerations: Ensure the operating environment adheres to the specified temperature, humidity, and vibration limits for optimal performance and longevity.
8. Initial Power-Up: After all connections are verified, restore power and observe the system's boot-up sequence.
