Siemens

Siemens 6ES7193-4CA20-0AA0 SIMATIC ET 200S Terminal Module

SKU 6ES7193-4CA20-0AA0

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6ES7193-4CA20-0AA0
  • Origin Germany
  • Product Type: Terminal Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.95 kg
  • Dimensions: 2.5 cm x 5.1 cm x 83.8 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

SIMATIC ET 200S Terminal Modules
Quantità
Call sales Contact

Product Description

Description

This is a Siemens 6ES7193-4CA20-0AA0 terminal module, specifically engineered for the SIMATIC ET 200S distributed I/O system. The module provides a reliable termination base for narrow electronic modules with a 15 mm width, making it suitable for high-density control cabinet applications where space is a primary concern. It features robust screw-type terminals for secure field wiring and includes integrated access to the AUX1 auxiliary bus, which simplifies the process of daisy-chaining common potentials like power or ground across multiple modules, reducing installation time and wiring complexity.

Features

  • Designed for the Siemens SIMATIC ET 200S I/O system.
  • Accommodates 15 mm wide electronic modules.
  • Features secure and reliable screw-type terminals.
  • Provides 2x4 terminal connections for field devices.
  • Includes terminal access to the AUX1 auxiliary bus for efficient power distribution.
  • Facilitates compact and high-density cabinet layouts.

Applications

  • Distributed I/O systems in manufacturing and assembly lines.
  • Process control and automation panels.
  • Material handling and conveyor systems.
  • Building automation and HVAC control cabinets.
  • High-density machine control applications.

Technical Specifications

Specification Value
Manufacturer Siemens
Part Number 6ES7193-4CA20-0AA0
Product Series SIMATIC ET 200S
Module Type Terminal Module
Termination Method Screw-type terminals
Terminal Connections 2x4
Supported Module Width 15 mm
Lifecycle Status Active
Condition Brand New
Country of Origin Germany
Shipping Weight 0.95 kg
Package Dimensions (Calculated) 2.5 cm x 5.1 cm x 83.8 cm
HS Code 8537101190

Installation Guidelines

CRITICAL WARNING: HAZARD OF ELECTRIC SHOCK

Disconnect all power sources before installation or maintenance. Failure to de-energize equipment can result in severe injury or death. Installation must be performed by qualified personnel familiar with applicable codes and standards.

  1. 1
    De-energize System: Verify that the control panel and all related power sources are de-energized and locked/tagged out (LOTO) according to site safety procedures. Use a calibrated multimeter to confirm zero energy state.
  2. 2
    Mount on DIN Rail: Securely mount the terminal module onto the designated 35 mm DIN rail within the ET 200S station. Ensure it is correctly oriented and clicks firmly into place adjacent to the preceding module.
  3. 3
    Install Electronic Module: Carefully insert the corresponding 15 mm electronic module into the terminal module until it is fully seated. The coding elements on both modules should align to prevent incorrect installation.
  4. 4
    Connect Field Wiring: Terminate prepared field wires into the screw terminals. Use the correct wire gauge and strip length. Ensure a secure mechanical connection by tightening each screw to the specified torque. Verify that no stray wire strands are present.
  5. 5
    System Verification: After all modules are installed and wired, remove locks/tags and re-energize the system. Commission the I/O point to verify correct operation and communication with the controller.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What automation system is the 6ES7193-4CA20-0AA0 designed for?
This terminal module is specifically designed for use within the Siemens SIMATIC ET 200S distributed I/O system.
What type of wire connections does this module use?
It features screw-type terminals, which provide a secure and reliable mechanical connection for field wiring.
What is the purpose of the AUX1 bus access?
The terminal access to the AUX1 auxiliary bus is designed to simplify wiring by allowing for easy daisy-chaining of common potentials, such as power or ground, across multiple modules in the station.
What is the width of the electronic modules compatible with this terminal base?
This terminal module is engineered to interface with narrow electronic modules that have a width of 15 mm.
Is this an active component?
No, the 6ES7193-4CA20-0AA0 is a passive terminal module that provides the physical connection points for an active electronic module and field devices.
