Siemens 6ES7288-2DR08-0AA0 SIMATIC S7-200 SMART Digital Output Module DR08

SKU 6ES7288-2DR08-0AA0

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6ES7288-2DR08-0AA0
  • Origin Germany
  • Product Type: PLC Digital Output Modules
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.95 kg
  • Dimensions: 25 x 51 x 838 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Output Modules SIMATIC S7-200 SMART
Quantità
Call sales Contact

Product Description

Description

This is the Siemens 6ES7288-2DR08-0AA0, an 8-channel digital output module for the SIMATIC S7-200 SMART PLC system. It provides flexible control capabilities through eight independent relay outputs, each capable of switching loads up to 2A. The module connects directly to the S7-200 SMART backplane bus and is designed for controlling a variety of industrial devices such as motors, valves, and contactors. It operates on a nominal 24V DC power supply and includes reverse polarity protection for enhanced system reliability.

Features

  • Eight independent relay output channels.
  • Supports switching of both AC and DC loads.
  • Maximum switching current of 2A per output.
  • Integrates seamlessly with the SIMATIC S7-200 SMART backplane.
  • Features reverse polarity protection for the power supply.
  • Compact design for standard DIN rail mounting.

Applications

  • Automated assembly lines
  • Conveyor and material handling systems
  • Packaging machinery
  • Control of small motors, solenoids, and indicator lamps

Technical Specifications

Specification Value
Manufacturer Siemens
Part Number 6ES7288-2DR08-0AA0
Product Family SIMATIC S7-200 SMART
Module Type Digital Output Module (SM DR08)
Number of Outputs 8
Output Type Relay
Switching Current per Channel 2 A (max)
Supply Voltage (L+) 24V DC
Operating Voltage Range 20.4 V to 28.8 V DC
Current Consumption from Backplane Bus 90 mA at 5V DC
Current Consumption from L+ 80 mA (typical) at 24V DC
Protection Reverse polarity protection
Module Dimensions (W x H x D) 175 x 100 x 80 mm
Module Weight 0.54 kg
Country of Origin Germany
Package Dimensions (Calculated) 25 x 51 x 838 mm

Installation Guidelines

CRITICAL WARNING: Hazardous voltages may be present. Installation, wiring, and maintenance must be performed by qualified personnel only. Ensure all power sources to the PLC rack and associated equipment are de-energized and locked out (LOTO) before proceeding.
  1. 1
    Verify that the module part number 6ES7288-2DR08-0AA0 is compatible with your specific SIMATIC S7-200 SMART CPU and system configuration.
  2. 2
    De-energize the PLC system, including the 24V DC power supply and any field device power sources connected to existing modules. Confirm absence of voltage.
  3. 3
    Securely mount the module onto the DIN rail adjacent to the CPU or the preceding I/O module, ensuring it is properly seated.
  4. 4
    Engage the module's backplane bus connector with the adjacent module to establish a secure data and power connection.
  5. 5
    Terminate the field wiring for the relay outputs at the module's terminal block. Ensure correct wire gauge and secure connections for the expected load currents.
  6. 6
    Connect the external 24V DC power supply to the module's power terminals, observing correct polarity (+/-).
  7. 7
    After verifying all connections, remove the LOTO and re-energize the system. Proceed with software configuration and commissioning.
