Description

The Siemens 6ES7647-5EJ10-0CX0 SIMATIC Box PC 620 is a robust industrial computer engineered for demanding production environments. This unit features an onboard AGP graphics adapter configurable to 8, 16, or 32 MB, ensuring suitable visual output for industrial applications. Network connectivity is provided by a 10/100 Mbit/s Ethernet RJ45 interface for efficient data processing and communication. Equipped with a Celeron 1.2 GHz processor and 256 KB SLC cache, the 6ES7647-5EJ10-0CX0 delivers reliable performance for continuous operation. It includes 128 MB SDRAM-133 memory and a 40 GB EIDE HDD for storage, complemented by a combo drive supporting CD-R/RW/DVD formats and a 1.44 MB, 3.5" floppy drive. Versatile connectivity options include two USB ports, a PC Card (PCMCIA Type 3) slot, and expansion capabilities with one PCI and one ISA/PCI free slot. Additional industrial interfaces such as PROFIBUS/MPI (12 Mbit/s) and TTY are integrated, alongside a watchdog and temperature monitoring for enhanced system reliability. The unit is supplied with a 110/230V industry-rated power pack (with NAMUR compliance) and a European power cable. Pre-installed with Windows NT 4.0 Workstation (English, Service Pack 5), the 6ES7647-5EJ10-0CX0 is prepared for immediate integration into industrial automation setups, supporting continuous productivity and secure operations.

Features

• Celeron 1.2 GHz Processor with 256 KB SLC Cache
• 128 MB SDRAM-133 Memory
• Onboard AGP Graphics (8/16/32 MB configurable)
• 10/100 Mbit/s Ethernet RJ45 Interface
• 40 GB EIDE Hard Disk Drive
• CD-R/RW/DVD Combo Drive and 1.44 MB 3.5" Floppy Drive
• PROFIBUS/MPI (12 Mbit/s) and TTY Interfaces
• 2 x USB Ports and 1 x PC Card (PCMCIA Type 3) Slot
• 1 x PCI and 1 x ISA/PCI Free Expansion Slots
• Integrated Watchdog and Temperature Monitoring
• 110/230V Industry Power Pack with NAMUR Compliance
• Pre-installed Windows NT 4.0 Workstation (English, SP5)

Applications

The Siemens SIMATIC Box PC 620 is suitable for a wide range of industrial applications requiring a robust and reliable computing platform, including:

• Machine control and visualization systems
• Data acquisition and processing in manufacturing environments
• Process control and monitoring
• Industrial communication gateways
• Human-Machine Interface (HMI) applications
• Integration into existing automation infrastructures with legacy interfaces (ISA, TTY)

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. Power Connection: Connect the provided European power cable to the 110/230V industry power pack. Ensure the power source meets the specified voltage requirements.
2. Mounting: Securely mount the SIMATIC Box PC 620 in a suitable industrial enclosure or panel, ensuring adequate ventilation to prevent overheating.
3. Peripheral Connections: Connect necessary peripherals such as monitors (via AGP graphics), keyboards, and mice to the available USB ports.
4. Network and Fieldbus: Connect the Ethernet RJ45 cable for network communication and PROFIBUS/MPI cables for fieldbus integration as per system architecture.
5. Expansion Cards: If utilizing expansion slots, carefully install PCI or ISA/PCI cards, ensuring proper seating and securing mechanisms.
6. System Startup: Power on the unit. The pre-installed Windows NT 4.0 Workstation (SP5) should initiate. Configure network settings and application software as required for your specific industrial automation task.
7. Environmental Considerations: Operate the PC within specified temperature and humidity ranges for industrial equipment. Utilize the integrated temperature monitoring for proactive system health checks.
