Description

The Siemens 6ES7647-6CB00-0BX0 is a SIMATIC IPC627C Box PC designed for industrial applications, offering robust performance and connectivity. This unit features onboard HD graphics and a Celeron P4505 processor (2C/2T, 1.86 GHz, VT, 2 MB cache). It provides extensive communication options including two 10/100/1000 Mbit/s Ethernet RJ45 ports, four high-current USB V2.0 ports, and one serial (COM1) port. An onboard RAID controller enhances data integrity, while a front-accessible CompactFlash drive slot offers flexible storage expansion. The system includes watchdog, temperature, and fan monitoring for reliable operation. For industrial communication, it supports PROFIBUS/MPI (CP 5611-A2-compatible) and comes with 2 MB buffered SRAM and 1 GB DDR3 1066 DIMM. Power is supplied via an AC 110/230V industrial power supply unit with NAMUR compatibility and includes a European power supply cable. The IPC627C also features two free PCI slots, a 250 GB SATA HDD, and is pre-installed with Windows 7 Ultimate 32 Bit SP1, MUI (English, German, French, Italian, Spanish).

Features

• Onboard HD Graphics
• Dual 10/100/1000 Mbit/s Ethernet (RJ45)
• Four USB V2.0 ports (high current)
• One serial (COM1) port
• Integrated RAID Controller
• Front-accessible CompactFlash drive slot
• Watchdog, temperature, and fan monitoring
• Celeron P4505 Processor (2C/2T, 1.86 GHz, VT, 2 MB Cache)
• PROFIBUS/MPI (CP 5611-A2-compatible)
• 2 MB Buffered SRAM
• 1 GB DDR3 1066 DIMM RAM
• AC 110/230V Industrial Power Supply Unit with NAMUR
• Two free PCI expansion slots
• 250 GB SATA Hard Disk Drive
• Pre-installed Windows 7 Ultimate 32 Bit SP1, MUI

Applications

The Siemens SIMATIC IPC627C Box PC is suitable for a wide range of industrial automation tasks, including:

• Machine control and visualization (HMI)
• Data acquisition and processing
• Process control systems
• Manufacturing execution systems (MES)
• Industrial communication gateways
• Distributed control systems (DCS)

Technical Specifications

Connections / Interfaces

The SIMATIC IPC627C provides the following external interfaces:

• 2 x RJ45 ports for 10/100/1000 Mbit/s Ethernet
• 4 x USB V2.0 ports (high current)
• 1 x Serial port (COM1)
• PROFIBUS/MPI interface (CP 5611-A2-compatible)

Installation Guidelines

1. De-energize System: Before installation, ensure all power to the system and associated equipment is completely de-energized and locked out to prevent electrical shock.
2. Mounting: Securely mount the Box PC in a suitable industrial enclosure or rack, ensuring adequate ventilation and clearance for cable routing and maintenance.
3. Power Connection: Connect the AC 110/230V industrial power supply unit to a stable power source. Ensure proper grounding of the unit and the enclosure.
4. Ethernet Connections: Connect industrial Ethernet cables to the RJ45 ports for network communication. Use shielded cables in noisy industrial environments.
5. USB and Serial Connections: Connect peripheral devices to the USB V2.0 ports and serial devices to the COM1 port as required by the application.
6. PROFIBUS/MPI Connection: If utilizing PROFIBUS/MPI, connect the appropriate cable to the interface, ensuring correct termination and shielding for reliable fieldbus communication.
7. Cable Management: Route all cables neatly and securely, separating power cables from signal cables to minimize electromagnetic interference.
8. Environmental Considerations: Ensure the operating environment meets the specified temperature and humidity ranges for industrial PC operation. Protect the unit from excessive dust, moisture, and vibration.
