6ES7647-8AH70-3BA1

Siemens

Siemens 6ES7647-8AH70-3BA1 SIMATIC IPC277D Nanobox PC

SKU 6ES7647-8AH70-3BA1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6ES7647-8AH70-3BA1
  • Origin Germany
  • Product Type: Nanobox PC
  • Barcode: 85371099
  • Payment: T/T, Western Union
  • Weight: 2.35 kg
  • Dimensions: 34.40 x 30.10 x 18.90 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Nanobox PC SIMATIC IPC277D
Quantità
Call sales Contact

Product Description

Description

The Siemens 6ES7647-8AH70-3BA1 is a SIMATIC IPC277D Nanobox PC designed for industrial automation applications. This compact industrial PC features an Atom E660 (1.3 GHz) processor, 2 GB RAM, and 8 GB SIMATIC PC CompactFlash for retentivity. It includes a DVI-I graphics card connection, two 10/100/1000 Mbps Ethernet RJ45 ports, and four high-current USB V2.0 ports. Power is supplied via a 24 V DC industrial power supply. The unit also provides a Compact Flash slot and a COM1 RS232 interface, running on WES 7 SP1 and supporting WINAC RTX 2010 for embedded control tasks. It is designed for standard mounting rail installation.

Features

  • 1x DVI-I Graphics Card Connection
  • 2x 10/100/1000 Mbps Ethernet RJ45 Ports
  • 4x USB V2.0 Ports (High Current)
  • Compact Flash Slot
  • 24 V DC Industrial Power Supply
  • Atom E660 Processor (1.3 GHz)
  • 2 GB RAM
  • 8 GB SIMATIC PC CompactFlash for Retentivity
  • COM1: RS232 Interface
  • Pre-installed WES 7 SP1 Operating System
  • Supports WINAC RTX 2010
  • Designed for Standard Mounting Rail Installation

Applications

  • Industrial control systems
  • Data acquisition and processing
  • Human Machine Interface (HMI) applications
  • Embedded automation solutions
  • Distributed control systems (DCS)

Technical Specifications

Manufacturer Siemens
Product Range Simatic Box PC
Subrange IPC277D
Product Type Nanobox PC
PLM Product Phase Phase-Out
Processor Atom E660 (1.3 GHz)
RAM 2 GB
Retentivity Storage 8 GB SIMATIC PC CompactFlash
Operating System WES 7 SP1
PLC Runtime Support WINAC RTX 2010
Power Supply 24 V DC Industrial
Graphics Interface 1x DVI-I
Ethernet Ports 2x 10/100/1000 Mbps RJ45
USB Ports 4x V2.0 (High Current)
Serial Interface COM1: RS232
Storage Expansion Compact Flash Slot
Mounting Type Standard Mounting Rail
Country of Origin Unknown
Package Dimensions (Calculated) 34.40 x 30.10 x 18.90 cm
Shipping Weight 2.35 kg
Commodity Code 85371099
Export Control Regulations (ECCN) N

Connections / Interfaces

  • DVI-I Port
  • Ethernet RJ45 Ports
  • USB V2.0 Ports
  • Compact Flash Slot
  • RS232 (COM1) Port
  • DC Power Input Terminals

Installation Guidelines

  1. Safety First: Ensure all power to the installation area is de-energized before beginning installation.
  2. Mounting: Securely mount the Nanobox PC onto a standard mounting rail. Ensure adequate clearance for ventilation and cable routing.
  3. Power Connection: Connect the 24 V DC industrial power supply to the designated power input terminals. Observe correct polarity.
  4. Interface Connections:
    • Connect DVI-I compatible displays to the graphics port.
    • Connect Ethernet cables to the RJ45 ports for network communication.
    • Connect USB devices to the USB V2.0 ports.
    • Connect serial devices to the COM1 RS232 port as required.
    • Insert a Compact Flash card into the designated slot if additional storage or system image is needed.
  5. Grounding: Ensure the unit is properly grounded according to local electrical codes and Siemens guidelines to prevent electrical interference and ensure safety.
  6. Cable Management: Route all cables to minimize stress on connectors and avoid interference with other components.
  7. Power Up: After all connections are verified, re-energize the power supply.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the 6ES7647-8AH70-3BA1?
This unit is a compact industrial PC (Nanobox PC) designed for embedded control and automation tasks, featuring an Atom E660 processor and various industrial interfaces.
What operating system is pre-installed on this Nanobox PC?
The unit comes with Windows Embedded Standard 7 SP1 (WES 7 SP1) pre-installed.
What type of power supply does this Nanobox PC require?
It requires a 24 V DC industrial power supply.
Can this unit be expanded with additional storage?
Yes, it includes a Compact Flash slot for additional storage or system images.
What is the purpose of the 8 GB CompactFlash for retentivity?
The 8 GB SIMATIC PC CompactFlash provides non-volatile storage for retaining data and system settings even after power cycles, crucial for industrial applications.
Reviews

More from this brand

Siemens 3RW4447-6BC45 SIRIUS 3RW44 Soft Starter
3RW4447-6BC45Siemens 3RW4447-6BC45 SIRIUS 3RW44 Soft Starter
Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 226 Compact Unit
6ES7216-2BD23-0XB0Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 226 Compact Unit
Phoenix Contact IBS S5 DSC/I-T 2752000 Termination Board for Siemens SIMATIC S5 PLCs
IBSS5DSC/I-T 2752000Phoenix Contact IBS S5 DSC/I-T 2752000 Termination Board for Siemens SIMATIC S5 PLCs
BECKHOFF KL8001 Bus Terminal Power Terminal for Siemens Contactor
KL8001BECKHOFF KL8001 Bus Terminal Power Terminal for Siemens Contactor

6ES7647-8AH70-3BA1

Stock & lead time on request

Call
  • 6ES7647-8AH70-3BA1
1 1

Siemens 6ES7647-8AH70-3BA1 SIMATIC IPC277D Nanobox PC

Only 3 item(s) left in stock

  • Manufacturer: Siemens

  • Product No.: 6ES7647-8AH70-3BA1

  • Country of origin:Germany

  • Product Type: Nanobox PC

  • Barcode: 85371099

  • Payment: T/T, Western Union

  • Weight: 2350g

  • Dimensions: 34.40 x 30.10 x 18.90 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
