Description

The Siemens 6AV7885-2AK10-2AA1 is a SIMATIC HMI IPC 577C Panel PC designed for industrial human-machine interface applications. This unit features a 15-inch touch display, an Intel Core 2 Duo 1.86 GHz processor, and 1 GB DDR3 RAM. It includes a PCI slot for expansion and provides extensive connectivity with four USB ports on the back, one USB port on the front, and two 1 Gbit Ethernet ports (10/100/1000). The Panel PC also integrates PROFINET (IE) capabilities. For mass storage, it comes equipped with a 2 GB CF card, with the operating system being optional. The device operates on a 110/230 V AC power supply unit with NAMUR compatibility, making it suitable for various industrial environments.

Features

• 15-inch touch display for interactive operation
• Intel Core 2 Duo 1.86 GHz processor
• 1 GB DDR3 RAM
• 2 GB CF card for primary mass storage (operating system optional)
• Integrated PROFINET (IE) interface
• Two 1 Gbit Ethernet ports (10/100/1000)
• Four rear USB ports and one front USB port
• PCI slot for system expansion
• 110/230 V AC power supply unit with NAMUR support

Applications

The Siemens SIMATIC HMI IPC 577C Panel PC is suitable for a range of industrial applications requiring robust computing and visualization, including:

• Machine operation and control
• Process visualization and monitoring
• Data acquisition and logging
• Operator interface in manufacturing and automation systems
• Integration into distributed control systems (DCS)

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. De-energize System: Ensure all power to the installation area and associated equipment is disconnected and locked out before beginning any work.
2. Mounting: Securely mount the Panel PC in a suitable industrial enclosure or panel cutout, ensuring adequate ventilation and clearance for cable routing and maintenance.
3. Power Connection: Connect the 110/230 V AC power supply to the designated terminals, observing correct polarity and ensuring a stable power source. Verify the NAMUR compatibility if applicable to your system.
4. Grounding: Establish a proper protective earth (PE) connection to the Panel PC chassis to ensure electrical safety and minimize electromagnetic interference.
5. Peripheral Connections: Connect USB devices, Ethernet cables, and PROFINET connections to their respective ports. Ensure all cables are securely fastened and routed to prevent strain or damage.
6. Environmental Considerations: Operate the Panel PC within specified temperature and humidity ranges. Protect the unit from excessive dust, moisture, and vibration.
7. System Startup: After all connections are verified, re-energize the system and power on the Panel PC. Monitor for proper boot-up and system functionality.
