Description

The Siemens 6ES7715-1BB22-0AA0 is a SIMATIC Field PG M3 Premium, an industrial notebook engineered for programming, commissioning, and maintaining automation systems in demanding factory environments. This device is equipped with an Intel Core i5-520M processor, 3 GB of DDR3 RAM, and a 500 GB SATA HDD for reliable performance and data storage. It features a high-resolution 15.6-inch Full HD display, ideal for complex process visualization and software development. This specific configuration is supplied without the legacy S5 interface or S5-EPROMMER, targeting modern automation infrastructures. The unit includes pre-installed software trial licenses and power cables for use in the USA and Japan.

Features

• Processor: Intel Core i5-520M running at 2.4 GHz.
• Memory: 3 GB DDR3 RAM (configured as 1x 1 GB and 1x 2 GB modules).
• Storage: 500 GB SATA Hard Disk Drive (HDD).
• Display: 15.6-inch Full HD screen with 1920 x 1080 resolution.
• Optical Drive: DL Multi-Standard DVD RW for flexible data transfer.
• Keyboard: QWERTY layout with German character set.
• Operating System: Windows XP Professional (English MUI) with German, French, Spanish, and Italian images.
• Included Software: Trial licenses for STEP 7 Professional and WinCC flexible Advanced (Version 04/2010).
• Approvals: Certified for use in the USA (FCC) and Canada (IC).

Applications

• PLC and HMI programming and configuration.
• Commissioning and startup of industrial machinery.
• On-site diagnostics and troubleshooting of automation systems.
• System maintenance and software updates in the field.
• Data logging and analysis directly on the plant floor.

Technical Specifications

Installation and Handling Guidelines

1. 1 Upon receipt, visually inspect the Field PG for any signs of physical damage incurred during transit. Do not power on a damaged unit.
2. 2 Select the correct power supply cable (USA or Japan provided) and connect it to a stable, grounded AC power source. Verify the integrity of the power supply and cabling before connection.
3. 3 Power on the device and allow the operating system to boot completely. Verify basic functionality before proceeding to connect to any industrial network or controller.
4. 4 When connecting to a plant network or directly to a PLC, use high-quality, properly shielded communication cables (e.g., PROFIBUS, PROFINET). Ensure network settings are correctly configured to avoid IP conflicts or communication errors.
5. 5 Operate the Field PG on a stable, level surface. Keep ventilation openings clear to prevent overheating. Avoid exposure to excessive dust, moisture, vibration, or extreme temperatures common in industrial settings.
6. 6 Always follow plant-specific Lockout-Tagout (LOTO) procedures before connecting to or disconnecting from energized equipment. Confirm the system is in a safe state before downloading new configurations or forcing I/O.
