Siemens 6FC5103-0AE01-0AA1 | Siemens | SINUMERIK 840C/840CE Operator Panel Interface

SKU 6FC5103-0AE01-0AA1

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6FC5103-0AE01-0AA1
Origin Germany
Product Type: Operator Panels
Barcode: 85044095
Payment: T/T, Western Union
Weight: 1.83 kg
Dimensions: 23.50cm x 17.00cm x 20.50cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

The 6FC5103-0AE01-0AA1 is a specialized keyboard interface module engineered for the Siemens SINUMERIK 840C and 840CE CNC control systems. This unit serves as the critical communication bridge between custom customer control panels and the CNC controller, facilitating robust I/O management. It supports a comprehensive configuration of 64 digital inputs and 48 digital outputs, handling power supply ranges of 115-230 V AC to ensure reliable signal processing in industrial machine tool environments.

Features

System Integration: Purpose-built for SINUMERIK 840C/840CE CNC architectures.
High I/O Density: Facilitates connectivity for up to 64 inputs and 48 outputs, supporting complex machine control panels.
Voltage Versatility: Designed for standard industrial power environments operating at 115-230 V AC.
Reliable Communication: Ensures high-speed signal transmission between operator interface hardware and the main processing unit.

Applications

Upgrade or repair of legacy CNC machining centers.
Custom machine tool operator panel integration.
Maintenance and sustainment of SINUMERIK 840-series automation systems.
Industrial HMI (Human-Machine Interface) signal management.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Model	6FC5103-0AE01-0AA1
Range	SINUMERIK 840
Product Type	Operator Panel / Keyboard Interface
Inputs	64
Outputs	48
Supply Voltage	115-230 V AC
Product Phase	Phase-Out
Dimensions	23.50 cm x 17.00 cm x 20.50 cm
Weight	1.83 kg
Export Control (ECCN)	EAR99

Installation Guidelines

Electrical Safety: Always isolate the control system from the primary power source before connecting or disconnecting the interface module.
Grounding: Ensure the module chassis is properly bonded to the cabinet's protective earth (PE) system to maintain noise immunity and safety.
Wiring Practices: Use appropriate cable shielding for I/O connections to minimize electromagnetic interference (EMI) originating from motor drives or high-frequency switching components.
Terminal Management: Verify that all 64 inputs and 48 outputs are correctly mapped in the SINUMERIK configuration software to prevent logic errors during machine operation.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What systems is the 6FC5103-0AE01-0AA1 compatible with?

This keyboard interface module is specifically designed for use with Siemens SINUMERIK 840C and 840CE CNC systems.

How many I/O points does this interface support?

The unit supports 64 digital inputs and 48 digital outputs for custom control panel connectivity.

What power supply does the module require?

It is designed to operate within an industrial power range of 115-230 V AC.

Is this product current in Siemens' catalog?

No, the product is currently in the 'Phase-Out' stage, making it primarily available for maintenance and repair of existing installations.
