Description

Engineered to facilitate flexible installation of network hardware, the Weidmuller IE-WALLMOUNT-KIT-30MM (Article Number 1504450000) provides a reliable mechanical solution for adapting standard DIN rail-mounted Industrial Ethernet components to flat-surface wall installations. This mounting kit eliminates the requirement for a dedicated DIN rail section in compact enclosures or open-wall setups, allowing direct integration of switches, routers, and media converters into diverse industrial environments. By utilizing this robust adapter, engineers can optimize space utilization within control cabinets and field enclosures while maintaining secure device positioning.

Features

• Enables alternative wall-mounting of top-hat DIN rail-based components.
• Compatible with 30mm wide Industrial Ethernet modules.
• Lightweight, robust mechanical design minimizing additional load on mounting surfaces.
• RoHS compliant construction ensuring adherence to environmental safety standards.

Applications

• Industrial control panels and compact electrical enclosures.
• Telecommunication and network distribution cabinets.
• Factory automation networks with limited DIN rail space.
• Field-level device mounting in harsh industrial environments.

Technical Specifications

Installation Guidelines

To ensure secure installation of your Industrial Ethernet components, follow these engineering guidelines:

• Securely fasten the mounting kit to the wall or flat surface using appropriate mounting screws suitable for the substrate material.
• Align the Industrial Ethernet component's DIN rail clip mechanism with the mounting kit adapter interface.
• Press the component onto the adapter until the locking mechanism fully engages and clicks into place.
• Verify mechanical stability by gently pulling on the module to ensure it does not detach under vibration.
• Maintain adequate clearance around the mounted device to allow proper ventilation and prevent cable strain.

Compliance and Certifications

• RoHS: Conform
