Kabel Sambungan Bently Nevada 330930-045-04-CN 3300 NSv

Kabel Sambungan Bently Nevada 330930-045-04-CN 3300 NSv

Hanya 2 item tinggal dalam stok

  • Pengilang: Bently Nevada

  • No. Produk: 330930-045-04-CN

  • Negara asal:Amerika Syarikat

  • Jenis Produk: Kabel Sambungan 3300 NSv

  • Kod bar: 8537101190

  • Pembayaran: T/T, Western Union

  • Berat: 120g

  • Dimensi: 45 mm x 90 mm x 90 mm (H x W x D)

  • Pelabuhan penghantaran: Xiamen

  • Jaminan: 12 bulan

Lihat butiran penuh
Penerangan Produk
FAQ
Penghantaran Pemulangan
Butiran tambahan
Ulasan

Description

Option 045 (4.5 m cable length) and Option 04 (stainless steel armor with FEP jacket and connector protector) specify this 3300 NSv extension cable configuration - 330930-045-04-CN.

This cable transmits high-frequency radio signals between the 3300 NSv proximity probe and the 3300 XL NSv Proximitor sensor. The stainless steel armor prevents physical abrasion in heavy-industry setups, while the fluorosilicone connector protector seals the ClickLoc connection from process contaminants. This model includes China-specific hazardous area certifications under the -CN suffix, qualifying it for restricted industrial environments requiring NEPSI and CCC compliance.

Features

  • Cable length of 4.5 meters (14.8 feet) matching specific system length requirements
  • Stainless steel armor with FEP jacket providing mechanical protection and chemical resistance
  • Integrated connector protector to seal the probe-to-cable joint
  • Gold-plated brass ClickLoc coaxial connectors for secure locking connections
  • Suffix -CN certification for NEPSI and CCC hazardous area approvals in China

Applications

  • Shaft vibration and axial position measurements in small-bore machinery
  • Aeroderivative gas turbine vibration monitoring
  • Centrifugal and axial compressors with restricted installation clearances
  • High-speed machinery requiring reduced target areas and specialized sensor positioning

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330930-045-04-CN 3300 NSv Extension Cable
A - Cable Length Option 045 4.5 meters (14.8 feet)
B - Connector and Cable Option 04 With stainless steel armor, with FEP jacket, with connector protector
Suffix -CN -CN China hazardous area approval package (NEPSI + CCC + applicable markings)

Technical Specifications

Manufacturer Bently Nevada
Part Number 330930-045-04-CN
Product Type 3300 NSv Extension Cable
System Compatibility 3300 XL NSv Proximity Transducer System
Cable Length 4.5 meters (14.8 feet)
Armoring Option Stainless steel armor with FEP jacket
Connector Protection Pre-installed connector protector
Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Center Conductor Resistance 0.220 ohm/m (0.067 ohm/ft)
Shield DC Resistance 0.066 ohm/m (0.020 ohm/ft)
Cable Outer Diameter (Unarmored) 2.80 mm (0.11 in) max
Armored Outer Diameter 7.6 mm (0.30 in) max with FEP jacket
Minimum Bend Radius 25.4 mm (1.0 in)
Cable-to-Connector Pull Strength 220 N (50 lb)
Operating and Storage Temperature -52 degC to +177 degC (-62 degF to +351 degF)
Relative Humidity Limit 100% condensing, non-submersible (with protected connectors)

Installation Guidelines

  • Route the extension cable through conduit or trays to prevent physical damage.
  • Maintain a minimum bend radius of 25.4 mm (1.0 in) along the run.
  • Ensure the ClickLoc connectors are hand-tightened and locked before sealing.
  • Slip the integrated connector protector over the probe-to-extension-cable connection to prevent liquid ingress.
  • Do not exceed the maximum pull strength of 220 N (50 lb) during installation.

Compliance and Certifications

The 3300 NSv extension cable meets specific approvals when installed as part of a complete transducer system:

  • China Hazardous Area Approvals: NEPSI and CCC certified under the -CN option package.
  • ATEX/IECEx: Intrinsically safe (Ex ia IIC Ga) and non-sparking/increased safety (Ex nA/Ex ec IIC Gc) system installations.
  • North American Approvals (CSA): Class I, Division 1 and 2, Groups A, B, C, D (when installed per system drawings).
Loading product navigation…
Key Features:
#Bently Nevada 3300 NSv #Extension Cable

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Kabel Sambungan Bently Nevada 330930-045-04-CN 3300 NSv

Download Open in new tab

What does the -CN suffix indicate on this 3300 NSv extension cable?
The -CN suffix indicates that the cable is supplied with the China hazardous area approval package, which includes NEPSI and CCC certifications.

What cable options are included with the option 04 code?
Option 04 specifies that this cable has stainless steel armor, a protective FEP jacket over the armor, and a pre-installed connector protector on the female connector.

What is the total length of the 330930-045-04-CN cable?
This cable has a total length of 4.5 meters (14.8 feet). It must be paired with the correct probe length to match the Proximitor sensor's calibrated system length.

What is the minimum bend radius for this armored extension cable?
The minimum bend radius is 25.4 mm (1.0 in), which must be maintained during installation to prevent signal degradation or physical damage.
