The TU515 is an S500-eCo I/O terminal unit designed for analog and 24 VDC digital modules in ABB distributed automation systems. It provides screw terminal connections for field wiring integration within PLC and process control applications.
The unit supports reliable signal termination for S500-eCo I/O assemblies and is intended for use with ABB analog and digital modules operating at 24 V DC. The 1SAP212200R0001 terminal unit is suitable for industrial cabinet installations requiring compact DIN rail-mounted wiring infrastructure.
Its screw terminal design allows secure field cable connections for distributed I/O architectures. The TU515 is used in ABB PLC automation environments where organized signal routing and modular I/O expansion are required.
The terminal unit is designed for industrial automation systems including machine control, process monitoring, and distributed control applications.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product ID | 1SAP212200R0001 |
| ABB Type Designation | TU515 |
| Product Main Type | TU515 |
| Series | S500-eCo I/O |
| Product Name | Distributed Automation I/Os |
| Function | For analog and 24 VDC digital modules. Screw terminals |
| Terminal Type | Screw terminals |
| Supply Voltage | 24 V DC |
| Number of Analog Configurable I/Os | 0 |
| Degree of Protection | IP20 |
| Operating Temperature | 0 ... +60 degC |
| Storage Temperature | -40 ... +70 degC |
| Product Width | 67.5 mm |
| Product Height | 135 mm |
| Product Depth | 28 mm |
| Net Weight | 0.232 kg |
| Gross Weight | 0.262 kg |
| EAN | 4016779649223 |
| CN8 | 85389091 |
| eClass | 27-24-22-92 |
| ETIM 8 | EC000810 - PLC mounting rack |
| UNSPSC | 32151703 |
| Selling Unit | piece |
Install the terminal unit on a grounded DIN rail inside an industrial control cabinet. Maintain sufficient clearance for cable routing and ventilation around adjacent I/O modules.
Separate signal wiring from high-voltage power cables to reduce electromagnetic interference. Ensure screw terminals are properly tightened according to field wiring practices to maintain stable electrical connections.
Verify compatibility with associated S500-eCo analog and 24 VDC digital modules before commissioning the system.
