Allen-Bradley 1783-ETAP2F Stratix EtherNet/IP Tap

SKU 1783-ETAP2F

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: 1783-ETAP2F
  • Origin United States
  • Product Type: 1+2 Port EtherNet/IP Taps
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.26 kg
  • Dimensions: 132 mm x 48 mm x 105 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EtherNet/IP Tap

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Allen-Bradley 1783-ETAP2F Stratix EtherNet/IP Tap

Download Open in new tab
Quantity
Call sales Contact

Product Description

Description

The Allen-Bradley 1783-ETAP2F is a 3-port industrial network interface component engineered to provide flexible connectivity options inside an EtherNet/IP network deployment. This specialized EtherNet/IP Tap features one local copper port paired with two fiber optic ports to facilitate the integration of single-port field devices into linear, star, or high-availability Device-Level Ring (DLR) communication networks. By combining copper and fiber connections, the module helps extend network media segments across greater plant distances while simultaneously protecting critical processing loops from external electromagnetic interference. The device seamlessly interfaces with industrial automation equipment, programmable controllers, and distributed I/O nodes to maintain reliable data transmission pathways and optimize plant uptime.

Features

  • Equipped with 1 local copper RJ45 port supporting 10/100 Mbps autosensing data transfer rates.
  • Features 2 multimode fiber optic LC ports designed for reliable 100 Mbps transmission loops.
  • Supports high-availability industrial network structures including linear links and Device-Level Ring (DLR) topologies.
  • Housed inside a compact, rugged IP20 rated enclosure optimized for space-restricted industrial enclosures.
  • Operates on a standard 24V DC input supply path with low power consumption.

Applications

  • Device-Level Ring (DLR) machinery segments requiring reliable network loop fault tolerance.
  • Long-distance industrial networking runs that require the noise isolation advantages of fiber optic media.
  • Distributed controller and field device integration over mixed-media communication backbones.

Technical Specifications

Attribute Specification
Manufacturer Allen-Bradley
Catalog Number 1783-ETAP2F
Product Type EtherNet/IP Tap
Product Series Stratix
Copper Interfaces 1 RJ45 Port (10/100 Mbps)
Fiber Interfaces 2 LC Multimode Ports (100 Mbps, 100Base-FX)
Power Supply 24V DC (20.4...27.6V DC, Class 2)
Current Rating 260 mA
Power Consumption 4.8W
Enclosure Type IP20
Operating Temperature -25...60 Celsius (-13...140 Fahrenheit)
Network Media Male RJ45 to Male RJ45 Patchcord, Unshielded Twisted Pair, Teal TPE Cable, 1.9 m
Recommended Cable Class Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 242



Installation Guidelines

  • Install the tap hardware firmly onto a clean, symmetrical top-hat DIN rail within a protective industrial control enclosure.
  • Connect a regulated 24V DC external power loop to the designated input terminal block, adhering strictly to Class 2 power supply constraints.
  • Terminate local network connections by running high-quality unshielded twisted-pair (UTP) Category 5e copper patchcords to the RJ45 port.
  • Establish long-distance trunk connections by plugging multimode fiber cables equipped with proper LC connectors directly into the twin fiber ports.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the device in an industrial control topology?
The device acts as a three-port media tap that connects individual industrial automation components with single Ethernet interfaces directly into linear or fault-tolerant Device-Level Ring networks.
What connection physical configurations are provided on the unit interface?
The unit is outfitted with one copper RJ45 port supporting 10/100 Mbps data rates and two fiber optic ports using LC multimode connection standards at 100 Mbps.
What are the ambient temperature constraints for safe deployment of the module?
The module is rated for safe industrial application within a monitored ambient operating temperature range from -25 Celsius up to +60 Celsius.
