Allen-Bradley 80190-480-01-R PowerFlex 7000 Drive Control Board

SKU Allen Bradley 80190-480-01-R

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: Allen Bradley 80190-480-01-R
  • Origin United States
  • Product Type: Drive Control Board
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.46 kg
  • Dimensions: 27.8cm x 21.4cm x 2.8cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Drive Control Boards Powerflex 7000
Quantity
Call sales Contact

Product Description

Description

The Allen-Bradley 80190-480-01-R is a drive control circuit board designed for deployment within PowerFlex 7000 medium voltage variable frequency drive systems. This module coordinates real-time processing and provides multi-motor orchestration, managing the operational profiles of up to four independent motors from a singular interface. Equipped with extensive discrete processing blocks, it supports the tracking and execution of system functions using 16 digital inputs and 16 digital outputs. The Allen-Bradley 80190-480-01-R provides essential signal logic and system diagnostic interfacing across high-power industrial power topologies.

Features

  • Coordinates speed and torque regulation commands for multi-motor applications controlling up to 4 motors.
  • Built-in discrete processing matrix featuring 16 digital inputs and 16 digital outputs for local system interfacing.
  • Direct compatibility with the control rack assembly inside air-cooled or liquid-cooled drive enclosures.
  • Integrates seamlessly with low-voltage control circuits to supervise high-power electrical systems safely.

Applications

  • Multi-motor drive control systems operating in heavy industries like mining, oil and gas, and water management.
  • Control processing loop monitoring for fans, large pumps, and heavy material conveyors.
  • Retrofitting and maintaining discontinued hardware components in operational automated drive networks.

Technical Specifications

Specification Value
Manufacturer Allen-Bradley / Rockwell Automation
Model 80190-480-01-R (8019048001R)
Product Series PowerFlex 7000
Component Type Drive Control Board
Motor Control Capacity Up to 4 motors
Operating Voltage 480 VAC
Current Rating 15 Amp
Power Rating 7.2 kW
Digital Inputs 16
Digital Outputs 16
Status Discontinued by manufacturer

Installation Guidelines

  • Disconnect, tag out, and verify that all medium voltage and auxiliary control voltage power sources are completely isolated before attempting any board handling or installation procedures.
  • Ensure a properly grounded anti-static wrist strap is worn continuously throughout the removal and installation process to shield the board's electronics from electrostatic discharge (ESD).
  • Fasten the card into its designated slot within the low-voltage control bay, guaranteeing that all plastic standoffs or mounting hardware lock securely into place.
  • Double-check terminal alignment and pin configurations before plugging wire looms or optical links back into their ports to avoid wiring errors.
