Allen-Bradley 80190-100-01-R Fiber Optic Board

SKU 80190-100-01-R

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Allen-Bradley
Product No.: 80190-100-01-R
Country of origin:United States
Product Type: Fiber Optic Board
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 350g
Dimensions: 28 mm x 145 mm x 120 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 80190-100-01-R is an optical interface printed circuit board engineered by Rockwell Automation to provide robust power regulation and isolated fiber optic communication interfaces. The 80190-100-01-R serves as a dependable power conversion module that delivers a stable 24V DC output up to 10A from an adjustable input range of 100-240V AC. This hardware integrates multi-channel fiber optic transmitter and receiver paths alongside power regulation components, ensuring stable power delivery and transient-immune communication interfaces for demanding industrial automation applications.

Features

Dual-function architecture supporting integrated 240W DC power regulation and optical communication links
Onboard status diagnostics featuring dedicated RUN and READY light-emitting diodes
Highly efficient input voltage adaptation protecting secondary control circuitry from primary AC spikes

Applications

Industrial variable frequency drive systems
Electro-optically isolated power distributions
Process automation control networks

Technical Specifications

Parameter	Specification
Manufacturer	Allen-Bradley / Rockwell Automation
Model Number	80190-100-01-R
Alternate Board Marking	80190-099-01/6
Input Voltage Range	100-240V AC
Output Voltage Range	24V DC
Maximum Output Current	10A
Power Output	240W (max)
Enclosure Type	IP20
Operating Temperature Range	-20 degC to 60 degC (-4 degF to 140 degF)
Storage Temperature Range	-40 degC to 85 degC (-40 degF to 185 degF)
Country of Origin	Canada (Designed in USA)

Installation Guidelines

Electrostatic Discharge Protection: This assembly utilizes electrostatic sensitive devices; maintain strict ESD grounding rules throughout the physical installation process.
Cooling/Ventilation: Mount the hardware within an appropriate industrial enclosure that complies with the -20 degC to 60 degC functional thermal bounds.
Cable Routing: Fasten fiber optic terminations directly into the marked TX/RX ports while maintaining minimal bend radius profiles to mitigate optical transmission damping.

Compliance and Certifications

CE
UL
RoHS compliant

FAQ

What input voltage configuration is supported by the device?

The device accepts a universal input voltage range from 100V AC to 240V AC.

What is the maximum current rating for the power module portion?

The power circuit delivers a maximum output current up to 10A at a regulated 24V DC.

What are the storage temperature thresholds for this board?

The safe storage temperature parameters are specified between -40 degC and +85 degC.
