Bently Nevada 16710-13 Interconnect Cable

Description

The 16710-13 is a high-quality interconnect cable designed for use with Bently Nevada acceleration transducers, specifically the 330400 and 330425 series. This cable configuration provides a 13.0 ft (3.96 m) length to facilitate reliable signal transmission in critical machinery monitoring applications, such as gear mesh monitoring and casing vibration analysis.

This cable features a 3-conductor shielded 22 AWG (0.5 mm2) construction, ensuring signal integrity in industrial environments. One end is terminated with a 3-socket plug for mating with the transducer, while the other end is fitted with terminal lugs for easy connection to monitoring instrumentation or terminal blocks. Proper installation using this shielded cable helps minimize false signals and maintains the frequency response characteristics of the connected accelerometer.

Features

• 13.0 ft (3.96 m) cable length
• 3-conductor shielded 22 AWG (0.5 mm2) wire
• 3-socket plug connector for 330400/330425 series transducers
• Terminal lug termination at the monitoring end
• Designed for critical machinery acceleration measurements

Applications

• Casing vibration monitoring
• Gear mesh monitoring
• Rotating machinery protection
• Industrial acceleration transducer integration

Ordering Information

Technical Specifications

Installation Guidelines

Ensure the cable is routed away from high-voltage lines to prevent electromagnetic interference. When installing the 3-socket plug onto the accelerometer, ensure the mating part provides at least IP54 ingress protection if exposed to industrial environments. Use appropriate cable clamps to relieve strain on the connector. For hazardous area installations, adhere to the local electrical codes and ensure the system is installed according to the Bently Nevada control drawings relevant to the 330400 series.
