330104-02-15-10-01-00: 3300 XL 8 mm proximity probe featuring metric M10 x 1 threads, built-in protective stainless steel armor (model 330104), a 20 mm unthreaded length (Option 02), a 150 mm overall case length (Option 15), a 1.0 m total length (Option 10), and a miniature coaxial ClickLoc connector with an integrated connector protector (Option 01) without agency approvals (Option 00).
In contrast to standard non-armored metric probes (model 330103) or variants lacking connector protection (Option 02), this specific configuration utilizes heavy-duty flexible stainless steel armor to safeguard the cable from mechanical abrasion, cutting, and crushing in harsh industrial environments. The integrated ClickLoc connector protector prevents moisture ingress and physical damage at the connection point to the extension cable, making it suitable for direct installation in demanding locations.
| Option / Segment | Code on This SKU | Meaning / Configuration Detail |
|---|---|---|
| Base Model | 330104 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 02 | 20 mm unthreaded length |
| B - Overall Case Length Option | 15 | 150 mm overall case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| E - Agency Approval Option | 00 | Not required |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number / Model | 330104-02-15-10-01-00 |
| Product Type | 3300 XL 8 mm Proximity Probe (with armor) |
| Thread Size | M10 x 1 (metric) |
| Unthreaded Length | 20 mm |
| Case Length | 150 mm |
| Total Length | 1.0 m (3.3 ft) |
| Cable Type | Standard coaxial cable with protective stainless steel armor |
| Connector Type | Miniature coaxial ClickLoc with connector protector |
| Scale Factor | 7.87 V/mm (200 mV/mil) when paired with a compatible 3300 XL Proximitor |
| Linear Range | 2.0 mm (80 mils) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Pressure Seal Rating | Up to 10.3 bar (150 psi) differential between tip and case |
| Weight | 0.35 kg |
| Dimensions (H x W x D) | 150 mm x 150 mm x 40 mm (H x W x D) |
The probe features a miniature coaxial ClickLoc connector. It connects directly to a 3300 XL standard extension cable. ClickLoc connectors provide a secure, positive lock that resists loosening from high-vibration conditions.
