Option 00 (0.0 in unthreaded length), Option 08 (0.8 in case length), and Option 12 (FluidLoc cable with ClickLoc connector) define this 3300 XL 8 mm proximity probe configuration — 330101-00-08-20-12-05. This unarmored, eddy-current transducer has a 2.0 m total length (Option 20) and carries hazardous area approvals (Option 05) for CSA, ATEX, and IECEx installations. It provides non-contact vibration and shaft position measurements by pairing with a 3300 XL Proximitor sensor and extension cable.
Unlike standard configurations with standard cable options, the integrated FluidLoc cable prevents lubricating oil and other process liquids from leaking out of the machine housing through the cable's interior. The short 0.8-inch fully-threaded case length is used in space-constrained bearing housings where mounting depth is limited. The system is fully interchangeable with other 3300 XL components, eliminating the need to match or bench calibrate individual pieces.
This transducer is used for rotating machinery monitoring:
| Option Segment | Code Value | Configuration Meaning |
|---|---|---|
| Orderable Part Number | 330101-00-08-20-12-05 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor |
| A - Unthreaded Length Option | 00 | 0.0 in (fully threaded case) |
| B - Overall Case Length Option | 08 | 0.8 in overall case length |
| C - Total Length Option | 20 | 2.0 meters (6.6 feet) total length |
| D - Connector and Cable-Type Option | 12 | Miniature coaxial ClickLoc connector, FluidLoc cable |
| E - Agency Approval Option | 05 | CSA, ATEX, IECEx Approvals for hazardous areas |
| Specification Parameter | Value / Details |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number / Model | 330101-00-08-20-12-05 |
| Probe Diameter | 8 mm |
| Measurement Type | Displacement (proximity) |
| Operating Principle | Eddy current |
| Thread Size | 3/8-24 UNF |
| Armoring | None (unarmored) |
| Cable Type | FluidLoc cable (oil leak barrier) |
| Connector Type | Miniature coaxial ClickLoc connector |
| Operating Temperature (Probe Tip) | -52 degC to +177 degC (-62 degF to +350 degF) |
| Operating Temperature (Probe Cable) | -52 degC to +177 degC (-62 degF to +350 degF) |
| Sealing | Viton O-ring pressure seal |
| System Compatibility | 3300 XL monitoring systems, Proximitor 330180 series, 3500 rack when appropriately interfaced |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
Mount the probe with the appropriate probe gap per system calibration standards. Route the cable with proper shielding and grounding practices to prevent electromagnetic interference. Keep the minimum thread engagement within standard limits to avoid binding during installation.
This configuration complies with the following approvals:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-08-20-12-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
