The Bently Nevada 330101-00-52-10-12-05 is a high-performance 8 mm proximity probe belonging to the industry-standard 3300 XL 8 mm Proximity Transducer System. This specific configuration is engineered for demanding industrial conditions where fluid migration through the sensor cable must be strictly controlled. It features a patented FluidLoc cable option (Option 12), which acts as an internal environmental seal to prevent lubricating oil, water, and other process liquids from leaking out of the machine housing through the core of the coaxial cable.
This non-armored probe is manufactured with a fully threaded 5.2 in case length (0.0 in unthreaded length) and 3/8-24 UNF threads, providing deep-reach capability into machinery bearing housings and casings. Utilizing eddy-current operating principles, it measures static shaft displacement and dynamic vibration without contacting the target surface. It connects to standard 330180 series Proximitor sensors and extension cables, delivering a highly linear output voltage that is directly proportional to the gap between the probe tip and the target. This probe is fully certified under option 05 for use in hazardous areas with CSA, ATEX, and IECEx certifications.
| Option Designation | Code on This SKU | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330101-00-52-10-12-05 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor |
| A - Unthreaded Length Option | 00 | 0.0 in (fully threaded case) |
| B - Overall Case Length Option | 52 | 5.2 in (132 mm) overall case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable-Type Option | 12 | Miniature coaxial ClickLoc connector, FluidLoc cable |
| E - Agency Approval Option | 05 | CSA, ATEX, and IECEx Approvals |
| Manufacturer | Bently Nevada |
| Part Number / Model | 330101-00-52-10-12-05 |
| Product Family | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Measurement Type | Displacement (proximity) |
| Operating Principle | Eddy current |
| Thread Size | 3/8-24 UNF (without armor) |
| Unthreaded Length | 0.0 in (0 mm) |
| Case Length | 5.2 in (132 mm) |
| Total Length | 1.0 meter (3.3 feet) |
| Cable Type | FluidLoc moisture/oil-blocking coaxial cable |
| Connector Type | Gold-plated miniature ClickLoc coaxial connector |
| Nominal Scale Factor | 7.87 V/mm (200 mV/mil) |
| Linear Range | 2.0 mm (80 mils), from approximately 0.25 mm to 2.25 mm (10 to 90 mils) |
| Nominal Probe DC Resistance (R_PROBE) | 7.59 ohms +/- 0.50 ohms (center conductor to outer conductor) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-52-10-12-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
