Bently Nevada 330103-00-11-50-02-00 3300 XL 8 mm Proximity Probe

SKU 330103-00-11-50-02-00

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330103-00-11-50-02-00
Origin United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.25 kg
Dimensions: 110 mm x 10 mm x 10 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

330103-00-11-50-02-00 is an unarmored metric 3300 XL 8 mm proximity probe configured with an M10 x 1 thread, 0 mm unthreaded length, and a 110 mm overall case length. This specific configuration features a 5.0 m (16.4 ft) standard FEP-insulated coaxial cable terminated with a miniature coaxial ClickLoc connector. It does not include an external armor sleeve or specialized hazardous area agency approval certifications, making it suitable for standard, non-classified industrial environments.

Unlike configurations like the 330104 series that incorporate flexible stainless steel armor, this probe uses a bare, flexible 75-ohm coaxial cable with a 3.68 mm outside diameter, facilitating routing through tight conduits. In contrast to the 1.0 m or 2.0 m variants, the 5.0 m total cable length connects directly to a matching 5-meter Proximitor sensor without requiring an intermediate extension cable, reducing potential signal attenuation and connector junctions in the measurement loop.

Features

Option 00 specifies a 0 mm unthreaded length, providing a fully threaded M10 x 1 case for maximum thread engagement.
Option 11 designates a 110 mm overall case length constructed from AISI 303 stainless steel.
Option 50 provides a 5.0-meter total cable length, eliminating the need for an external extension cable when paired with a 5-meter Proximitor sensor.
Option 02 provides a miniature coaxial ClickLoc connector without an integrated connector protector.
Option 00 designates standard approvals with no specialized hazardous area certifications.
Thread size of M10 x 1 matches metric mounting requirements without adapters.

Applications

Hydroelectric and steam turbine shaft vibration monitoring.
Radial vibration and axial position measurements on high-speed industrial compressors.
Rotating machinery shaft displacement monitoring in non-hazardous plant zones.
Hydraulic turbine shaft runout and absolute position tracking.

Ordering Information

Segment / Option	Code on This SKU	Description
Orderable Part Number	330103-00-11-50-02-00	3300 XL 8 mm Proximity Probe, M10 x 1 thread, without armor
A - Unthreaded Length Option	00	0 mm unthreaded length (fully threaded case)
B - Overall Case Length Option	11	110 mm overall case length (ordered in increments of 10 mm)
C - Total Length Option	50	5.0 meters (16.4 feet)
D - Connector and Cable-Type Option	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval Option	00	Not required (Standard approvals only)

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number / Model	330103-00-11-50-02-00
Dimensions	110 mm x 10 mm x 10 mm (H x W x D)
Weight	0.25 kg
Thread Size	M10 x 1
Unthreaded Length	0 mm
Case Length	110 mm
Total Probe Length	5.0 m (16.4 ft)
Probe Tip Diameter	8 mm (0.31 in)
Probe Tip Material	Polyphenylene sulfide (PPS)
Probe Case Material	AISI 303 or 304 stainless steel (SST)
Cable Outer Diameter	3.68 mm (0.145 in)
Cable Material	75-ohm triaxial FEP-insulated standard cable
Connector Type	Miniature male coaxial ClickLoc connector
Recommended Case Torque	7.5 N-m (66 in-lbf)
Maximum Rated Torque	22.6 N-m (200 in-lbf)
Operating and Storage Temperature	-52 degC to +177 degC (-62 degF to +350 degF)
Minimum Cable Bend Radius	25.4 mm (1.0 in)
Tensile Strength	330 N (75 lbf) probe case to probe lead

Installation Guidelines

Thread Engagement: Keep the thread engagement length below 15 mm during installation to prevent thread binding in the housing.
Tightening Torque: Tighten the probe case to the recommended torque of 7.5 N-m (66 in-lbf). Do not exceed 22.6 N-m (200 in-lbf).
Cable Routing: Maintain a minimum cable bend radius of 25.4 mm (1.0 in) to prevent cable fatigue and signal degradation.
Proximitor Selection: Match this 5.0-meter probe exclusively with a 5-meter Proximitor sensor. Using a mismatched sensor length will result in significant measurement errors.
Connector Handling: Fasten ClickLoc connectors finger-tight. Ensure connectors remain free of oil, moisture, and contaminants before mating.

Compliance and Certifications

Standard CE compliance.
Standard RoHS compliance.
No specialized hazardous area certifications (Option 00 designated as Not Required).

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What are the specific length parameters of this proximity probe?

The 330103-00-11-50-02-00 probe features a 110 mm case length, 0 mm unthreaded length (fully threaded body), and a 5.0-meter total cable length.

Can this 5.0-meter probe be paired with any Proximitor sensor?

No. A 5.0-meter probe must be paired specifically with a 5-meter Proximitor sensor. Pairing it with a different sensor length will cause severe calibration mismatch and measurement errors.

Does this probe configuration include a cable armor sleeve?

No. This configuration specifies Option 02, which features a standard unarmored FEP-insulated coaxial cable.

What is the thread specification and recommended mounting torque?

The probe case has an M10 x 1 metric thread. The recommended tightening torque is 7.5 N-m (66 in-lbf), and the absolute maximum torque is 22.6 N-m (200 in-lbf) to prevent thread damage.
