Option 00 (0 mm unthreaded) and Option 12 (miniature coaxial ClickLoc connector, FluidLoc cable) specify this 3300 XL 8 mm probe configuration — 330103-00-13-10-12-00. This unarmored, metric forward-mounted proximity probe features M10 x 1 threads, a 130 mm overall case length, and a 1.0-meter total cable length. The configuration is suited for installations requiring fluid-blocking performance, utilizing a specialized FluidLoc cable that stops oil or moisture from wicking along the interior of the cable jacket.
This transducer component operates on eddy-current principles to measure static or dynamic distance between the probe tip and a target, such as a rotating shaft. The absence of a connector protector on the miniature coaxial ClickLoc connector and the omission of agency approvals make this variant suitable for clean, non-hazardous industrial installations where external enclosures provide connection shielding.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-13-10-12-00 | 3300 XL 8 mm metric proximity probe, M10 x 1 thread, without armor |
| A - Unthreaded Length | 00 | 0 mm (fully threaded case) |
| B - Overall Case Length | 13 | 130 mm case length |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector and Cable-Type | 12 | Miniature coaxial ClickLoc connector, FluidLoc cable |
| E - Agency Approval | 00 | Not required / No hazardous area approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330103-00-13-10-12-00 |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Probe Type | Metric, standard forward-mount, without armor |
| Thread Size | M10 x 1 metric thread |
| Unthreaded Length | 0 mm (fully threaded case) |
| Overall Case Length | 130 mm (5.12 in) |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Cable Construction | 75 ohm triaxial FEP-insulated FluidLoc cable (prevents internal fluid wicking) |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 Stainless Steel (SST) |
| Operating and Storage Temperature | -52 to +177 Celsius (-62 to +350 Fahrenheit) |
| Connector Torque (Maximum) | 0.565 Nm (5 in-lbf) |
| Maximum Case Torque | 33.9 Nm (300 in-lbf) |
| Recommended Case Torque | 11.2 Nm (100 in-lbf) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength (Case to Lead) | 330 N (75 lbf) maximum rated |
| Tensile Strength (Lead to Connector) | 270 N (60 lbf) maximum rated |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) (Packaged/Coiled) |
| Weight | 0.15 kg (150 g) |
| Connector Component | Specification / Type |
|---|---|
| Probe Tip Connection | Integral coax cable terminated in ClickLoc coaxial connector |
| Connector Interface | Miniature male coaxial ClickLoc, gold-plated contacts |
| Mating Connector | Connects to 3300 XL standard extension cable female connector |
The 330103-00-13-10-12-00 configuration specifies Option 00 for agency approvals (no hazardous area approvals required). It is designed for use in general-purpose, non-hazardous industrial environments. The manufacturing facility for the 3300 XL transducer system is certified to ISO 9001 quality management standards.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-13-10-12-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 150g
Dimensions: 150 mm x 150 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
