Bently Nevada 330104-00-10-05-02-05 3300 XL 8 mm Proximity Probe

SKU 330104-00-10-05-02-05

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330104-00-10-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The 330104-00-10-05-02-05 is a 3300 XL 8 mm proximity probe configured with a 3/8-24 UNF thread, 0.0 in unthreaded length (Option 00), 1.0 in case length (Option 10), and a 0.5 m total length (Option 05). This transducer system, featuring a standard miniature ClickLoc coaxial connector (Option 02) and CSA/ATEX/IECEx hazardous area approvals (Option 05), is designed for reliable non-contact displacement measurement in critical rotating machinery.

As part of the Bently Nevada 3300 XL 8 mm system, this probe is compatible with 3300 XL Proximitor sensors and extension cables, forming a complete measurement chain for shaft vibration and axial position monitoring. The 330104 series includes integrated armor for mechanical protection in industrial environments, ensuring durability where cable abrasion is a risk.

Features

0.0 in Unthreaded Length (Option 00): Fully threaded probe body suitable for installations requiring minimal unthreaded clearance.
1.0 in Case Length (Option 10): Compact housing length for precise mounting in standard proximity probe brackets.
0.5 m Total Length (Option 05): System-matched cable length for integration with specific monitoring setups.
Standard ClickLoc Connector (Option 02): Miniature coaxial connector providing secure, reliable termination for eddy-current signal transmission.
Hazardous Area Approval (Option 05): Certified for use in CSA, ATEX, and IECEx rated hazardous environments.
Integrated Armor: Enhanced mechanical protection for the probe lead, suitable for high-vibration or abrasion-prone zones.

Applications

Critical rotating machinery vibration monitoring (turbines, compressors, pumps, motors).
Shaft axial position measurement (thrust monitoring).
High-abrasion environments requiring armored cable protection.
Hazardous industrial areas requiring international safety certifications (CSA, ATEX, IECEx).

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330104-00-10-05-02-05	3300 XL 8 mm Proximity Probe, M10 x 1 thread, armored
A - Unthreaded Length	00	0.0 in unthreaded length
B - Case Length	10	1.0 in overall case length
C - Total Length	05	0.5 meter (1.6 feet) total length
D - Connector/Cable	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330104-00-10-05-02-05
Probe Diameter	8.0 mm
Thread Size	M10 x 1
Cable Type	Armored
Connector Type	Miniature coaxial ClickLoc
Total System Length	0.5 m
Agency Approvals	CSA, ATEX, IECEx
Operating Temperature	-55 degC to +177 degC (dependent on application/probe type)

Installation Guidelines

Ensure the probe is installed in a probe clamp bracket to prevent mechanical stress on the threads.
Maintain a proper gap between the probe tip and the target material as specified by the 3300 XL monitoring system calibration.
For hazardous area installations, ensure compliance with Bently Nevada hazardous area drawing 141092 for 'ia' (intrinsically safe) or 140979 for 'nA/ec' (non-sparking/increased safety) ratings.
Ensure the Proximitor sensor is mounted in a location providing at least IP54 protection.

Compliance and Certifications

CSA, ATEX, IECEx: Certified for use in hazardous areas (Intrinsically Safe and Non-Sparking).

FAQ

What does the 330104-00-10-05-02-05 configuration define?

This part number specifies a 3300 XL 8 mm probe with 0.0 in unthreaded length (00), 1.0 in case length (10), 0.5 m total length (05), a standard ClickLoc connector (02), and CSA/ATEX/IECEx hazardous area approval (05).

Can I use this 0.5 m probe with a 5-meter Proximitor sensor?

No, 5-meter probes are designed specifically for use with 5-meter Proximitor sensors only. The total length of the probe and extension cable must match the calibrated length of the Proximitor sensor.

Is this probe suitable for hazardous areas?

Yes, this specific configuration (Option 05) includes CSA, ATEX, and IECEx approvals, making it suitable for hazardous environment installations when installed per relevant Bently Nevada drawings.

What is the difference between the 330104 and 330103 series?

The 330104 series includes integrated armor for cable protection, whereas the 330103 series is the unarmored version of the same 8 mm probe.

View all FAQs →

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.
