330106-05-30-05-12-05: 3300 XL 8 mm reverse mount proximity probe featuring metric M10 x 1 threads, 5 mm unthreaded length (Option 05), 30 mm case length (Option 30), 0.5 meter total length (Option 05), ClickLoc connector (Option 12), and CSA/ATEX/IECEx certifications (Option 05).
This probe configuration incorporates a FluidLoc cable (Option 12), which prevents process fluids and oil from migrating through the internal gaps of the cable into external environments. The reverse-mount housing allows thread installation from inside or from the opposite side of the mounting bracket, fitting tight spaces where standard front-mount options are impractical.
This proximity probe is used in rotating machinery protection and condition monitoring systems. Typical installations include shaft vibration, thrust position, and speed measurements on turbines, compressors, pumps, and generators across power generation, petrochemical, and oil and gas industries.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330106-05-30-05-12-05 | 3300 XL 8 mm Reverse Mount Proximity Probe, M10 x 1 thread |
| A - Unthreaded Length Option | 05 | 5 mm unthreaded length |
| B - Overall Case Length Option | 30 | 30 mm case length |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) |
| D - Connector and Cable-Type Option | 12 | Miniature coaxial ClickLoc connector, FluidLoc cable |
| E - Agency Approval Option | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330106-05-30-05-12-05 |
| Probe Tip Diameter | 8.0 mm |
| Thread Size | M10 x 1 |
| Unthreaded Length | 5 mm |
| Case Length | 30 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Cable Type | FluidLoc coaxial cable |
| Cable Outer Diameter | 3.94 mm |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Operating Temperature | -52 degC to +177 degC |
| Pressure Seal Limit | Up to 10.3 bar (150 psi) differential |
| Weight | 0.15 kg |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) |
Install the probe in an M10 x 1 threaded hole or matching bracket. Maximum thread engagement for this model is 15 mm. Tighten the ClickLoc coaxial connector finger-tight until it clicks. Do not exceed the maximum torque limits for M10 threads during body mounting.
This product complies with major international safety standards. Option 05 specifies certifications under CSA, ATEX, and IECEx for intrinsic safety and non-incendive installations in hazardous locations.
